Technical specifications
|
| Model: |
XTZ 660 Ténéré |
| Years: |
1993 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 5 valve
|
|
Capacity:
|
660 cc / 40.2 cu-in
|
|
Bore x Stroke:
|
100 x 84 mm
|
|
Cooling System:
|
Liquid cooled,
|
|
Compression Ratio:
|
9.2:1
|
|
Induction:
|
TEIKEI Y 26 PV / 3YF 00 carburetor
|
|
Ignition:
|
Transistor Controlled
|
|
Starting:
|
Electric
|
|
Max Power:
|
46 hp / 35.5 kW @ 6000 rpm
|
|
Max Power Rear Tyre:
|
42.9 hp @ 6400 rpm
|
|
Max Torque:
|
55.9 Nm / 42 ft. lb @ 5000 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Gear Ratio:
|
1st 2,583 2nd 1,588 3rd 1,200 4th 0,954 5th 0,792
|
|
Front Suspension:
|
43mm Telescopic forks
|
|
Rear Suspension:
|
Monocross adjustable for preload, 5-way rebound damping
|
|
Front Brakes:
|
Single 282mm disc 4 piston caliper
|
|
Rear Brakes:
|
Single 245mm disc 1 piston caliper
|
|
Front Tyre:
|
90/90-21
|
|
Rear Tyre:
|
120/90-17
|
|
Oil Capacity:
|
2.6 Litres
|
|
Dimensions:
|
Length 2265 mm / 89.1 in Width 885 mm / 34.8 in Height 1355 mm / 53.3 in
|
|
Seat Height:
|
865 mm / 34.1 in
|
|
Wheelbase:
|
1495 mm / 58.9 in
|
|
Dry Weight:
|
169 kg / 372.5 lbs
|
|
Wet Weight:
|
195 kg / 429 lbs
|
|
Fuel Capacity:
|
20 Litres / 5.3 US gal
|
|
Reserve:
|
3.5 Litres
|
|
Consumption Average:
|
16.7 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
14.7 m / 40.8 m
|
|
Standing ¼ Mile:
|
14.0 sec / 145.3 km/h
|
|
Top Speed:
|
167.5 km/h / 104 mph
|
|
Road Test:
|
Motosprint Group Test 1992
|
