1993 Yamaha XT 600E technical specifications

Technical specifications

Model: XT 600E
Years: 1993-94
Engine: Four stroke, single cylinder, SOHC, 4 valve
Capacity: 595 cc / 36.3 cu-in
Bore x Stroke: 95 x 84 mm
Cooling System: Air/oil cooled
Compression Ratio: 8.5:1
Oil Capacity: 1.6 Litres
Lubrication: Dry sump
Induction: Single 28mm Y26PV carburetor
Ignition: T.C.I.
Starting: Electric
Max Power: 45 hp / 32.8 kW @ 6500 rpm
Max Power Rear Tyre: 40.hp @ 6200 rpm
Max Torque: 50 Nm / 5.1 kg-m @ 5500 rpm
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: 41mm Telescopic forks, oil damped
Rear Suspension: Monocross with preload adjustment,
Front Brakes: Single 267mm discs 2 piston caliper
Rear Brakes: Single 220mm disc single piston caliper
Front Tyre: 90/90-21
Rear Tyre: 120/90-17
Dimensions: Length 2220 mm / 87.4 in Width 820 mm / 32.2 in Height 1245 mm / 49.0 in
Wheelbase: 1445 mm / 56.8 in
Seat Height: 855 mm / 33.6 in
Ground Clearance: 235 mm / 9.2 in
Dry Weight: 155 kg / 343 lbs
Wet Weight: 170 kg / 374.7 lbs
Fuel Capacity: 13 Litres / 3.4 US gal
Consumption Average: 18.5 km/lit
Braking 60 - 0 / 100 - 0: 14.0 m / 40.3 m
Standing ¼ Mile: 14.0 sec / 147.6 km/h
Top Speed: 165.1 km/h / 102.5 mph
Road Test: Motosprint Grup Test 1990
