Yamaha XT 1200Z Super Ténéré (2014) technical specifications

Yamaha XT 1200Z Super Ténéré technical specifications

Yamaha XT 1200Z Super Ténéré is produced in 2014. Engine is Four stroke, parallel twin cylinders, DOHC, 4-valve per cylinder, displacement 1199 cc / 73.2 cub in. , produces power 80.9 kW / 110 hp @7250 rpm and 114.0 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm.. Yamaha XT 1200Z Super Ténéré top speed is 192.3 km/h / 119.5 mph. Yamaha XT 1200Z Super Ténéré wet weight is 260 kg / 575 lbs. Yamaha XT 1200Z Super Ténéré has 7 photos.

Technical specifications

+ Add to 'Compare list'
Model: XT 1200Z Super Ténéré
Years: 2014
Engine: Four stroke, parallel twin cylinders, DOHC, 4-valve per cylinder
Capacity: 1199 cc / 73.2 cub in.
Bore x Stroke: 98 x 79.5 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Firing intervals: 270- and 450-degree points
Induction: Fuel injected, twin spark
Throttle system: Yamaha Chip-Controlled Throttle (YCC-T)
Yamaha D-MODE: 2 modes, Sport (S) and Touring (T)
Traction control: 3 modes, TCS1, TCS2 and OFF
Lubrication: Dry sump
Motor oil: Semi-synthetic
Ignition: TCI
Starting: Electric
Max Power: 80.9 kW / 110 hp @7250 rpm
Max Torque: 114.0 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm.
Clutch: Wet, multiple-disc diaphragm spring
Transmission: 6 Speed
Final Drive: Shaft
Frame: Steel tube backbone
Front Suspension: Upside-down telescopic fork, 43 mm inner tube, adjustable preload, compression and rebound damping,
Front wheel travel: 190 mm / 7.4 in
Rear Suspension: Monoshock, adjustable preload and rebound damping,
Rear wheel travel: 190 mm / 7.4 in
Front Brakes: 2 x 310mm disc, ABS / Unified Brake System
Rear Brakes: Single 282 mm disc
Front Tyre: 110/80 R19
Rear Tyre: 150/70/ R17
Rake: 28°
Trail: 126mm / 5 in.
Dimensions: Length: 2,255mm / 88.8 in Width: 980mm / 38.6 in Height: 1,410mm / 55.5 in
Wheelbase: 1540 mm / 60.6 in
Seat Height: 845 mm - 870 mm / 33.2 in - 34.2 in Adjustable
Ground Clearance: 205 mm / 8.1 in
Oil Capacity: 4.2 Liters / 4.4 Quarts
Wet Weight: 260 kg / 575 lbs
Fuel Capacity: 23 Liters / 5.1 US gal
Fuel Consumption: 6.1 L/100 km / 16.4 km/1 / 38.6 US mpg
Standing ¼ Mile: 12.5 sec / 168.5 km/h / 104.7 mph
Standing 1000 m: 24.5 sec / 189.8 km/h / 117.9 mph
Top Speed: 192.3 km/h / 119.5 mph
