1976 Yamaha XS 360 technical specifications

Technical specifications

Model: XS 360
Years: 1976-77
Engine: Four stroke, parallel twin cylinder, 180° crankshaft, SOHC, 2 valves per cylinder.
Capacity: 359 cc / 21 cu-in
Bore x Stroke: 66 x 52,4 mm
Cooling System: Air cooled
Compression Ratio: 8.7:1
Induction: Mikuni 34mm CV-carburetors
Ignition: Battery and contact breaker points
Starting: Electric starter supplied with kick starter.
Max Power: 34 hp @ 8500rpm
Max Torque: 3,0 kg/m / 21.6 lb-ft @ 7500rpm
Transmission / Drive: 6 Speed
Final Drive: Chain
Front Suspension: Telescopic fork.
Rear Suspension: Swingarm, dual shocks with adjustable spring preload.
Front Brakes: Single 267mm disc 1 piston caliper
Rear Brakes: Single 267mm disc 1 piston caliper
Front Tyre: 3.00-18
Rear Tyre: 3.50-18
Dry Weight: 159 kg / 350.5 lbs
Wet Weight: 176 kg / 388 lbs
Fuel Capacity: 11 Litres / 2.9 US gal
Consumption Average: 60 mpg
Standing ¼ Mile: 14.3 sec
Top Speed: 169 km/h / 105 mph
Road Test: Motorcyclist 1976
