Yamaha XP 530 T-Max Bronze MAX Special (2014) technical specifications

Yamaha XP 530 T-Max Bronze MAX Special technical specifications

Yamaha XP 530 T-Max Bronze MAX Special is produced in 2014. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder., displacement 530 cc / 32.34 cu-in , produces power 45.8 hp / 34.2 kW @ 6750 rpm and 52.3 Nm / 38.6 ft.lbs @ 5250 rpm. Yamaha XP 530 T-Max Bronze MAX Special weighs 203 kg / 447.5 lbs - ABS 208 kg / 458.5 lbs. Yamaha XP 530 T-Max Bronze MAX Special has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: XP 530 T-Max Bronze MAX Special
Years: 2014
Engine: Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder.
Capacity: 530 cc / 32.34 cu-in
Bore x Stroke: 68.0 x 73.0 mm
Cooling System: Liquid cooled
Compression Ratio: 10:9 : 1
Lubrication: Semi-dry-sump
Induction: Injection. Electronic fuel injection
Ignition: TCI
Starting: Electric
Max Power: 45.8 hp / 34.2 kW @ 6750 rpm
Max Torque: 52.3 Nm / 38.6 ft.lbs @ 5250 rpm
Clutch: Wet, multiple-disc automatic
Transmission: Fully automatic CVT
Final Drive: V-Belt
Front Suspension: 43mm Telescopic forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Swingarm - single shock
Rear Wheel Travel: 116 mm / 4.6 in
Front Brakes: 2x 267 discs
Rear Brakes: Single 267 disc
Front Tyre: 120/70-15
Rear Tyre: 160/60-15
Dimensions: Length 2200mm / 86.6 in Width 775mm / 30.5 in Height 1420 or 1475mm / 55.9 or 58.1 in
Ground Clearance: 125mm / 4.9 in
Wheelbase: 1580mm / 62.2 in
Maximum Load: 197kg / 434 lbs
Seat Height: 800 mm / 31.5 in
Dry Weight: 203 kg / 447.5 lbs - ABS 208 kg / 458.5 lbs
Wet Weight: 218 kg / 481 lbs
Fuel Capacity: 15 Litters / 4 gal
