2014 Yamaha XMAX 400 technical specifications
Technical specifications
|
|
|---|---|
| Model: | XMAX 400 |
| Years: | 2014-16 |
| Engine: | Four stroke, single cylinder, DOHC |
| Capacity: | 395 cc / 24.1 cu-in |
| Bore x Stroke: | 83 x 73 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.2:1 |
| Lubrication: | Wet sump |
| Induction: | Fuel Injection |
| Ignition: | ECU |
| Starting: | Electric |
| Max Power: | |
| Max Torque: | |
| Transmission: | Automatic |
| Final Drive: | V-Belt Automatic |
| Front Suspension: | Telescopic fork |
| Front Wheel Travel: | 110 mm / 4.3 in |
| Rear Suspension: | Unit swing |
| Rear Wheel Travel: | 110 mm / 4.3 in |
| Front Brakes: | Single 267mm disc |
| Rear Brakes: | Single 267mm disc |
| Front Tyre: | 120/70-15 |
| Rear Tyre: | 150/70-13 |
| Dimensions: | Width 780 mm / 30.7 in Length: 2,190 mm / 86.2 in |
| Wheelbase: | 1,565 mm / 61.6 in |
| Seat Height: | 785 mm / 30.9 in |
| Ground Clearance: | 105 mm / 4.1 in |
| Wet Weight: | 215 kg / 474 lbs |
| Fuel Capacity: | 14 Litres / 3.7 US gal |
