Yamaha XMAX 250 (2014-15) technical specifications

Yamaha XMAX 250 technical specifications

Yamaha XMAX 250 is produced in 2014-15. Engine is Four stroke, single cylinder, SOHC, displacement 249.7 cc / 15.2 cu-in , produces power 20.1 hp / 14.7 kW) @ 7500 rpm and 21 Nm / 15.5 lb-ft @ 6000 rpm. Yamaha XMAX 250 wet weight is 178 kg / 388. lbs - ABS 182 kg / 401 lbs. Yamaha XMAX 250 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: XMAX 250
Years: 2014-15
Engine: Four stroke, single cylinder, SOHC
Capacity: 249.7 cc / 15.2 cu-in
Bore x Stroke: 69 x 66.8 mm
Cooling System: Liquid cooled
Compression Ratio: 11.2:1
Lubrication: Wet sump
Induction: Fuel Injection
Ignition: TCI
Starting: Electric
Max Power: 20.1 hp / 14.7 kW) @ 7500 rpm
Max Torque: 21 Nm / 15.5 lb-ft @ 6000 rpm
Transmission: Automatic
Final Drive: Belt
Front Suspension: Telescopic fork, 110mm wheel travel.
Rear Suspension: Unit swing, 95mm wheel travel.
Front Brakes: Single 267mm disc
Rear Brakes: Single 240mm disc
Front Tyre: 120/70-M15
Rear Tyre: 140/70-M14
Dimensions: Height 1337 mm 52.6 in Length: 2220 mm / 87.4 in
Wheelbase: 1545 mm / 60.8 in
Seat Height: 792 mm / 31.2 in
Ground Clearance: 113 mm / 4.4 in
Wet Weight: 178 kg / 388. lbs - ABS 182 kg / 401 lbs
Fuel Capacity: 11.8 Liters / 3.3 gal
