Yamaha XMAX 125 (2018) technical specifications

Yamaha XMAX 125 is produced in 2018. Engine is Four stroke, single cylinder, displacement 124 cc / 7.6 cu-in , produces power 14 hp / 10.5 kW @ 8750 rpm and 12 Nm / 8.8 lb-ft @ 6500 rpm. Yamaha XMAX 125 wet weight is 175 kg / 385.8 lbs. Yamaha XMAX 125 has 11 photos.

Technical specifications

+ Add to 'Compare list'

Model:	XMAX 125
Years:	2018
Engine:	Four stroke, single cylinder
Capacity:	124 cc / 7.6 cu-in
Bore x Stroke:	52 x 58.6 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.2:1
Lubrication:	Wet sump
Induction:	Fuel Injection
Ignition:	Electronic TCI
CO2 emission:	63 g/km
Starting:	Electric
Max Power:	14 hp / 10.5 kW @ 8750 rpm
Max Torque:	12 Nm / 8.8 lb-ft @ 6500 rpm
Transmission:	Automatic
Final Drive:	Belt
Front Suspension:	Hydraulic telescopic fork
Front Wheel Travel:	110 mm / 4.3 in
Rear Suspension:	Hydraulic unit swing
Rear Wheel Travel:	75 mm / 2.9 in
Front Brakes:	Single 267mm disc
Rear Brakes:	Single 245mm disc
Front Tyre:	120/70-15
Rear Tyre:	140/70-14
Dimensions:	Height 1415 mm / 55.7 in Width 775 mm / 30.5 in Length 2185 mm / 86 in
Wheelbase:	1526 mm / 59.8 in
Seat Height:	795 mm / 31.2 in
Ground Clearance:	130 mm / 5.1 in
Wet Weight:	175 kg / 385.8 lbs
Fuel Capacity:	13 Litres / 3.4 US gal
