Yamaha XJ 700X Maxim (1986) technical specifications

Yamaha XJ 700X Maxim technical specifications

Yamaha XJ 700X Maxim is produced in 1986. Engine is Four stroke, transverse four cylinder, DOHC, 5 valves per cylinder, displacement 697.3 cc / 42.5 cu-in , produces power 64.1 kW / 86 hp @ 9500 rpm and 67.6 Nm / 49.9 ft-lb @ 8000 rpm. Yamaha XJ 700X Maxim weighs 215 kg / 474 lbs. Yamaha XJ 700X Maxim has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: XJ 700X Maxim
Years: 1986
Engine: Four stroke, transverse four cylinder, DOHC, 5 valves per cylinder
Capacity: 697.3 cc / 42.5 cu-in
Bore x Stroke: 68.0 x 48.0 mm
Cooling System: Liquid cooled
Compression Ratio: 11.2:1
Induction: 4x Standard side-draft 33 mm Mikuni CV
Ignition: Hitachi TID14-35 TCI
Starting: Electric
Max Power: 64.1 kW / 86 hp @ 9500 rpm
Max Torque: 67.6 Nm / 49.9 ft-lb @ 8000 rpm
Clutch: Wet/multi-disc
Transmission: 5 Speed
Final Drive: Shaft
Gear Ratio: 1st 35/16 (2.187) 2nd 30/20 (1.500) 3rd 30/26 (1.153) 4th 28/30 (0.933) 5th 26/32 (0.812)
Frame: Double Cradle
Front Suspension: 38mm Telescopic fork, air, coil spring, oil damper
Front Wheel Travel: 150 mm / 5.9 in cast aluminum 5-spoke
Rear Suspension: Swing arm Coil spring, oil damper
Rear Wheel Travel: 99 mm / 3.9 in cast aluminum hoop
Front Brakes: 2x discs 4 piston caliper
Rear Brakes: Drum
Front Tyre: 100/90-19 57H ( 90 mm depth)
Rear Tyre: 130/90-16 67H (117 mm depth)
Rake: 31.5°
Trail: 120 mm / 4.7 in
Dimensions: Length 2235 mm / 88.0 in Width 775 mm / 30.5 in Height 1160 mm / 45.7 in
Wheelbase: 1520 mm / 59.8 in
Seat Height: 760 mm / 29.9 in
Ground Clearance: 145 mm / 5.7 in
Dry Weight: 215 kg / 474 lbs
Wet Weight: 232 kg / 511 lbs
Fuel Capacity: 13 Litres / 3.43 US Gal
Related Link: maxim-x.com
