Yamaha XJ 600S Diversion (1992-95) technical specifications

Yamaha XJ 600S Diversion technical specifications

Yamaha XJ 600S Diversion is produced in 1992-95. Engine is Four stroke, transverse four cylinder, DOHC, 2 valves per cylinder, displacement 599 cc / 36.5 cu-in , produces power 61 hp / 45 kW @ 8.500 rpm and 33.9 lb-ft / 4.7 kgf-m @ 7000 rpm. Yamaha XJ 600S Diversion weighs 198 kg / 436.5 lbs. Yamaha XJ 600S Diversion has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: XJ 600S Diversion
Years: 1992-95
Engine: Four stroke, transverse four cylinder, DOHC, 2 valves per cylinder
Capacity: 599 cc / 36.5 cu-in
Bore x Stroke: 58.5 x 55.7 mm
Cooling System: Air cooled
Compression Ratio: 10:1
Lubrication: Wet sump
Induction: 4x 28mm Mikuni BDS28 downdraft carburettors
Ignition: Transistor
Starting: Electric
Max Power: 61 hp / 45 kW @ 8.500 rpm
Max Power Rear Tyre: 51.4 hp @ 8400 rpm
Max Torque: 33.9 lb-ft / 4.7 kgf-m @ 7000 rpm
Clutch: Wet multiple plate type
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2.733 2nd 1.778 3rd 1.333 4th 1.074 5th 5th 0.913 6th0.821
Frame: Double cradle
Front Suspension: 41mm Telescopic forks, no adjustment
Front Wheel Travel: 140 mm / 5.5 in
Rear Suspension: Monocross monoshock adjustable for preload
Rear Wheel Travel: 110 mm / 4.3 in
Front Brakes: 2x 320mm discs 2 piston caliper
Rear Brakes: Single 245mm disc 1 piston caliper
Wheels: 3 Spoke cast alloy wheel
Front Tyre: 110/80H17
Rear Tyre: 130/70H18
Rake: 25°
Trail: 97 mm / 3.8 in
Dimensions: Length 2170 mm / 85.4 in Width 770 mm / 30.3 in Height 1205 mm / 47.4 in
Wheelbase: 1445 mm / 56.8 in
Seat Height: 770 mm / 30.3 in
Ground Clearance: 150 mm / 5.9 in
Dry Weight: 198 kg / 436.5 lbs
Wet Weight: 213 kg / 469.5 lbs
Fuel Capacity: 17 Litres / 4.4 US gal
