Yamaha WR 250Z (1996) technical specifications

Yamaha WR 250Z technical specifications

Yamaha WR 250Z is produced in 1996. Engine is Two stroke, single cylinder, displacement 249 cc / 15.2 cu-in , produces power 49.8 hp / 37.2 kW @ 8250 rpm and 4.69 kgf-m / 44.5 Nm @ 7500 rpm. Yamaha WR 250Z weighs 103 kg / 227 lbs. Yamaha WR 250Z has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: WR 250Z
Years: 1996
Engine: Two stroke, single cylinder
Capacity: 249 cc / 15.2 cu-in
Bore x Stroke: 68 x 68.8 mm
Cooling System: Liquid cooled
Compression Ratio: 10.9:1
Lubrication: Premix
Induction: Mikuni VM38SS carburetor
Ignition: CDI
Starting: Kick
Max Power: 49.8 hp / 37.2 kW @ 8250 rpm
Max Torque: 4.69 kgf-m / 44.5 Nm @ 7500 rpm
Clutch: Multi-plate wet clutch
Transmission: 5 Speed
Final Drive: Chain
Frame: CrMo steel
Front Suspension: 43mm inverted fork
Front Wheel Travel: 300 mm / 11.8 in
Rear Suspension: Monocross, swinging arm
Rear Wheel Travel: 315 mm / 12.4 in
Front Brakes: Single 204mm disc
Rear Brakes: Single 189mm disc
Front Tyre: 80/100-21
Rear Tyre: 110/100-18
Wheelbase: 1480 mm / 58.2 in
Seat Height: 978 mm / 38.5 in
Ground Clearance: 398 mm / 15.6 in
Dry Weight: 103 kg / 227 lbs
Fuel Capacity: 13 Litres / 3.4 US gal
