Yamaha TRX 850 (1996-99) technical specifications

Yamaha TRX 850 technical specifications

Yamaha TRX 850 is produced in 1996-99. Engine is Four stroke, parallel twin cylinder, DOHC, 5 valves per cylinder, displacement 849 cc / 51.8 cu-in , produces power 79.7 hp / 58.6 kW @ 7500 rpm and 8.55 kgf-m 83.8 Nm @ 6000 rpm. Yamaha TRX 850 weighs 190 kg / 418.8 lbs. Yamaha TRX 850 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: TRX 850
Years: 1996-99
Engine: Four stroke, parallel twin cylinder, DOHC, 5 valves per cylinder
Capacity: 849 cc / 51.8 cu-in
Bore x Stroke: 89.5 x 67.5 mm
Cooling System: Liquid cooled
Compression Ratio: 10.5:1
Induction: 2x Mikuni BDST38 carbs
Ignition: TCI (Transistor Controlled Ignition)
Starting: Electric
Spark Plug: NGK, DPR8EA-9
Max Power: 79.7 hp / 58.6 kW @ 7500 rpm
Max Power Rear Tyre: 76.1 hp @ 7400 rpm
Max Torque: 8.55 kgf-m 83.8 Nm @ 6000 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 5 Speed
Final Drive: Chain
Frame: Steel, Trellis frame
Front Suspension: 41mm Telescopic fork Coil spring. oil damper
Rear Suspension: Swingarm Coil spring. gas-oil damper
Front Brakes: 2x 298mm discs 4 piston calipers
Rear Brakes: Single 248mm disc
Front Tyre: 120/60 ZR17
Rear Tyre: 160/60 ZR17
Dimensions: Length 2070 mm / 81.4 in Width 700 mm / 27.5 in
Wheelbase: 1435 mm / 56.4 in
Seat Height: 798 mm / 31.8 in
Dry Weight: 190 kg / 418.8 lbs
Wet Weight: 202 kg / 445.3 lbs
Fuel Capacity: 18 Litres / 4.7 US gal
Consumption Average: 16.8 km/lit
Standing ¼ Mile: 11.8 sec / 183.0 km/h
