Yamaha Ténéré 700 World Raid (2022) technical specifications

Yamaha Ténéré 700 World Raid technical specifications

Yamaha Ténéré 700 World Raid is produced in 2022. Engine is Four stroke, crossplane crankshaft parallel twin cylinder, DOHC, 4 valve per cylinder, displacement 689 cc / 42.04 cu-in , produces power 73.4 hp / 54 kW @ 9000 rpm and 68 Nm / 50 lb-ft @ 6500 rpm. Yamaha Ténéré 700 World Raid wet weight is 220 kg / 485 lbs. Yamaha Ténéré 700 World Raid has 10 photos.

Technical specifications

+ Add to 'Compare list'
Model: Ténéré 700 World Raid
Years: 2022
Engine: Four stroke, crossplane crankshaft parallel twin cylinder, DOHC, 4 valve per cylinder
Capacity: 689 cc / 42.04 cu-in
Bore x Stroke: 80 x 68.6 mm
Cooling System: Liquid cooled
Compression Ratio: 11.5:1
Lubrication: Wet sump
Induction: Fuel Injection
Emission: Euro 5
Ignition: TCI - Transistor Controlled Ignition
Starting: Electric
Max Power: 73.4 hp / 54 kW @ 9000 rpm
Max Torque: 68 Nm / 50 lb-ft @ 6500 rpm
Transmission: Constant Mesh, 6 Speed
Final Drive: Chain
Clutch: Wet multiplate
Frame: Double cradle, steel tube backbone
Front Suspension: 43mm Upside down telescopic fork, fully adjustable
Front Wheel Travel: 230 mm / 9.1 in
Rear Suspension: Single shock, adjustable preload (with remote adjuster) and rebound damping
Rear Wheel Travel: 220 mm / 8.7 in
Front Brakes: 2x 282mm Hydraulic discs
Rear Brakes: Single 245mm Hydraulic disc
ABS: Standard
Front Tyre: 90/90 R21 M/C 54V
Rear Tyre: 150/70 R18 M/C 70V M+S
Rake: 27°
Trail: 105 mm / 4.1 in
Dimensions: Length 2370 mm / 93.3 in Width 905 mm / 35.6 in Height 1490 mm / 58.7 in
Wheelbase: 1595 mm / 62.8 in
Seat Height: 890 mm / 35 in
Ground Clearance: 250 mm / 9.8 in
Wet Weight: 220 kg / 485 lbs
Fuel Capacity: 23 Litres / 6.0 US gal
