Yamaha RD 500LC / RZV500 / RZ 500 (1985) technical specifications
Yamaha RD 500LC / RZV500 / RZ 500 is produced in 1985. Engine is Two stroke, 50°-V4 cylinder, reed valve, YPVS, displacement 499 cc / 30.3 cu-in , produces power 88 hp / 63.9 kW @ 9500 rpm and 6.57 Nm / 6.9 kgf-m @ 8500 rpm. Yamaha RD 500LC / RZV500 / RZ 500 top speed is 148 mph / 238 km/h. Yamaha RD 500LC / RZV500 / RZ 500 weighs 180 kg / 437.8 lbs. Yamaha RD 500LC / RZV500 / RZ 500 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | RD 500LC / RZV500 / RZ 500 |
| Years: | 1985 |
| Engine: | Two stroke, 50°-V4 cylinder, reed valve, YPVS |
| Capacity: | 499 cc / 30.3 cu-in |
| Bore x Stroke: | 56.4 x 50 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 6.6 :1 |
| Induction: | 4x 26mm Mikuni carburetors |
| Ignition: | Digital CDI |
| Spark Plug: | NGK, BR9HS |
| Starting: | Kick |
| Max Power: | 88 hp / 63.9 kW @ 9500 rpm |
| Max Torque: | 6.57 Nm / 6.9 kgf-m @ 8500 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Gear Ratio: | 1st 2.250 2nd 1.685 3rd 1.363 4th 1.166 5th 1.043 6th 0.960 |
| Frame: | Steel twin downtube |
| Front Suspension: | 37mm Air assisted telescopic forks, 4-way spring preload adjustable and anti-dive variable. |
| Front Wheel Travel: | 140 mm / 5.5 in |
| Rear Suspension: | Monoshock, spring preload and rebound damping, |
| Rear Wheel Travel: | 120 mm / 4.7 in |
| Front Brakes: | 2x 267mm discs 2 piston calipers |
| Rear Brakes: | Single 245mm disc 2 piston calliper |
| Front Tyre: | 120/80 V16 + |
| Rear Tyre: | 130/80 V18 |
| Dimensions: | Length 2085 mm / 82.1 in Width 705 mm /27.7 in Height 1145 mm /45.0 in |
| Wheelbase: | 1375 mm / 54.1 in |
| Seat Height: | 780 mm / 30.7 in |
| Dry Weight: | 180 kg / 437.8 lbs |
| Wet Weight: | 198.6 kg / 436.5 lbs |
| Fuel Capacity: | 22 Litres / 5.8 gal |
| Consumption Average: | 27.5 mpg |
| Standing ¼ Mile: | 11.7 sec / 117.7 mph |
| Top Speed: | 148 mph / 238 km/h |
