Yamaha RD 125 (1973) technical specifications

Yamaha RD 125 technical specifications

Yamaha RD 125 is produced in 1973. Engine is Two stroke, parallel twin, displacement 124 cc / 7.6 cu-in , produces power 17 hp / 12.4 kW @ 8500 rpm and 1.3 kgf-m @ 8000 rpm. Yamaha RD 125 top speed is 81 mph. Yamaha RD 125 wet weight is 115 kg / 255 lbs. Yamaha RD 125 has 1 photos.

Technical specifications

+ Add to 'Compare list'
Model: RD 125
Years: 1973
Engine: Two stroke, parallel twin
Capacity: 124 cc / 7.6 cu-in
Bore x Stroke: 43 х 43 mm
Cooling System: Air cooled
Compression Ratio: 6.8:1
Induction: 2x 18mm Teikei carburetors
Ignition: Battery coil
Starting: Kick
Max Power: 17 hp / 12.4 kW @ 8500 rpm
Max Torque: 1.3 kgf-m @ 8000 rpm
Transmission: 5 Speed
Final Drive: Chain
Gear Ratio: (1) 34.52 (2) 19.67 (3) 14.11 (4) 11.34 (5) 9.11
Frame: steel tube engine used as a stressed member
Front Suspension: 28 mm telescopic forks
Rear Suspension: Dual rear shock pre-load adjustable
Front Brakes: 150 mm Drum
Rear Brakes: 130 mm Drum
Front Tyre: 2.75-18
Rear Tyre: 3.00-18
Wheelbase: 1245 mm / 49.0 in
Seat Height: 749 mm / 29.5 in
Wet Weight: 115 kg / 255 lbs
Fuel Capacity: 11.5 Litres / 3.04 US gal
Standing ¼ Mile: 18.2 sec
Top Speed: 81 mph
