Technical specifications
|
| Model: |
NMAX 125 |
| Years: |
2018 |
|
Engine:
|
Four stroke, single cylinder
|
|
Capacity:
|
124 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
52 x 58.6 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.2:1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
Fuel Injection
|
|
Ignition:
|
Electronic TCI
|
|
Starting:
|
Electric
|
|
Max Power:
|
12 hp / 9 kW @ 8750 rpm
|
|
Max Torque:
|
11.7 Nm / 8.8 lb-ft @ 6500 rpm
|
|
Transmission:
|
Automatic
|
|
Final Drive:
|
Belt
|
|
Front Suspension:
|
Hydraulic telescopic fork
|
|
Front Wheel Travel:
|
100 mm / 3.9 in
|
|
Rear Suspension:
|
Unit Swing
|
|
Rear Wheel Travel:
|
90 mm / 3.5 in
|
|
Front Brakes:
|
Single 230mm disc
|
|
Rear Brakes:
|
Single 230mm disc
|
|
Front Tyre:
|
110/70-13
|
|
Rear Tyre:
|
130/70-13
|
|
Dimensions:
|
Height 1115 mm / 43.8 in Width 740 mm / 29.1 in Length 1955 mm / 76.9 in
|
|
Wheelbase:
|
1350 mm / 53.1 in
|
|
Seat Height:
|
765 mm / 30.1 in
|
|
Ground Clearance:
|
135 mm / 5.5 in
|
|
Wet Weight:
|
127 kg / 280 lbs
|
|
Fuel Capacity:
|
6 Litres / 1.58 US gal
|
