Yamaha NMAX 125 (2015-17) technical specifications
Yamaha NMAX 125 is produced in 2015-17. Engine is Four stroke, single cylinder, displacement 124 cc / 7.6 cu-in , produces power 12 hp / 9 kW @ 8750 rpm and 11.7 Nm / 8.8 lb-ft @ 6500 rpm. Yamaha NMAX 125 wet weight is 127 kg / 280 lbs. Yamaha NMAX 125 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | NMAX 125 |
| Years: | 2015-17 |
| Engine: | Four stroke, single cylinder |
| Capacity: | 124 cc / 7.6 cu-in |
| Bore x Stroke: | 52 x 58.6 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.2:1 |
| Lubrication: | Wet sump |
| Induction: | Fuel Injection |
| Ignition: | Electronic TCI |
| Starting: | Electric |
| Max Power: | 12 hp / 9 kW @ 8750 rpm |
| Max Torque: | 11.7 Nm / 8.8 lb-ft @ 6500 rpm |
| Transmission: | Automatic |
| Final Drive: | Belt |
| Front Suspension: | Hydraulic telescopic fork |
| Front Wheel Travel: | 100 mm / 3.9 in |
| Rear Suspension: | Unit Swing |
| Rear Wheel Travel: | 90 mm / 3.5 in |
| Front Brakes: | Single 230mm disc |
| Rear Brakes: | Single 230mm disc |
| Front Tyre: | 110/70-13 |
| Rear Tyre: | 130/70-13 |
| Dimensions: | Height 1115 mm / 43.8 in Width 740 mm / 29.1 in Length 1955 mm / 76.9 in |
| Wheelbase: | 1350 mm / 53.1 in |
| Seat Height: | 765 mm / 30.1 in |
| Ground Clearance: | 135 mm / 5.5 in |
| Wet Weight: | 127 kg / 280 lbs |
| Fuel Capacity: | 6 Litres / 1.58 US gal |
