Yamaha FZ-1 Fazer (2015) technical specifications

Yamaha FZ-1 Fazer technical specifications

Yamaha FZ-1 Fazer is produced in 2015. Engine is Four stroke, transverse four cylinder, DOHC, 5 valve per cylinder, displacement 998 cc / 60.9 ci-in , produces power 146.8 hp / 108 kW @ 11000 rpm and 106 Nm /10.5 kgf-m / 76.7 ft-lb @ 8000 rpm. Yamaha FZ-1 Fazer weighs 198 kg / 436.5 lbs. Yamaha FZ-1 Fazer has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: FZ-1 Fazer
Years: 2015
Engine: Four stroke, transverse four cylinder, DOHC, 5 valve per cylinder
Capacity: 998 cc / 60.9 ci-in
Bore x Stroke: 77 X 53.6 mm
Cooling System: Liquid cooled
Compression Ratio: 11.5:1
Lubrication: Wet sump
Induction: Fuel injection
Ignition: Digital TCI: Transistor Controlled Ignition with 32-bit ECU
Starting: Electric
Max Power: 146.8 hp / 108 kW @ 11000 rpm
Max Torque: 106 Nm /10.5 kgf-m / 76.7 ft-lb @ 8000 rpm
Clutch: Wet, multiple discs, hydraulic operated
Transmission: 6 Speed
Final Drive: O-ring chain
Frame: Aluminium die-cast, diamond shaped
Front Suspension: Telescopic upside forks,
Front Wheel Travel: 130 mm / 5.1 in
Rear Suspension: Link-type swingarm,
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 245mm disc 1 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 190/50 ZR17
Rake: 25.0°
Trail: 109 mm / 4.3 in
Dimensions: Height 1204 mm / 47.4 in Length 2141 mm / 84.3 in Width 770 mm / 30.3 in
Wheelbase: 1461 mm / 57.5 in
Ground Clearance: 135 mm / 5.3 in
Seat Height: 815 mm / 32.1 in
Dry Weight: 198 kg / 436.5 lbs
Wet Weight: 221 kg / 487 lbs
Fuel Capacity: 18 Litres / 4.76 gal
