Yamaha FJR 1300A / AE / AS (ES in USA) (2017) technical specifications

Yamaha FJR 1300A / AE / AS (ES in USA) technical specifications

Yamaha FJR 1300A / AE / AS (ES in USA) is produced in 2017. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 1298 cc / 79.2 cu-in , produces power 105.7 kW / 146.2 hp @ 8000 rpm and 138 Nm / 14,1kgf-m / 101.8 lb-ft @ 7000 rpm. Yamaha FJR 1300A / AE / AS (ES in USA) wet weight is A: 288 kg / 635 lbs AE/ ES: 292 kg / 644 lbs AS: 296 kg / 653 lbs. Yamaha FJR 1300A / AE / AS (ES in USA) has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: FJR 1300A / AE / AS (ES in USA)
Years: 2017
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity: 1298 cc / 79.2 cu-in
Bore x Stroke: 79 x 66.2 mm
Compression Ratio: 10.8:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Induction: Yamaha Electronic Fuel Injection with YCC-T
Ignition: TCI: Transistor Controlled Ignition
Starting: Electric
Max Power: 105.7 kW / 146.2 hp @ 8000 rpm
Max Torque: 138 Nm / 14,1kgf-m / 101.8 lb-ft @ 7000 rpm
Clutch: Wet, multiple discs, hydraulic operated A/ES: Assist -and-Slipper clutch AS: Electronic clutch-less gearshift system
Transmission: 6 Speed
Final Drive: Shaft
Frame: Aluminium, diamond shaped
Front Suspension: 48mm Upside-down telescopic fork with adjustable preload, compression and rebound damping (AE/AS/ES: Suspension electronically adjustable)
Front Wheel Travel: 135 mm / 5.3 in
Rear Suspension: Single shock, link-type, with adjustable preload and rebound damping (AE/AS/ES: Suspension electronically adjustable)
Rear Wheel Travel: 124 mm / 4.9 in
Front Brakes: 2 x 320mm discs, 4 piston calipers, unified brake system, ABS
Rear Brakes: Single 282 mm disc, 2 piston caliper, unified brake system, ABS
Front Tyre: 120/70 ZR17
Rear Tyre: 180/55 ZR17
Dimensions: Length 2230 mm / 87.8 in. Width 749.3 mm / 29.5 in. Height 1455 mm / 57.3 in.
Wheelbase: 1544.3 mm / 60.8 in
Ground Clearance: 130 mm / 5.1 in.
Rake: 26.0°
Trail: 109 mm / 4.3 in.
Seat Height: 805 mm - 825.5 mm / 31.7 in - 32.5 in.
Wet Weight: A: 288 kg / 635 lbs AE/ ES: 292 kg / 644 lbs AS: 296 kg / 653 lbs
Fuel Capacity: 25 Litres / 6.6 gal
Oil Tank Capacity: 4.9 L / 10.4 US pts
Fuel Consumption: 6.5 L/100 km / 15.3 km/l / 36 US mpg
