Vespa PX125 T5, PX 125 T5 Elestart (1985-99) technical specifications
Vespa PX125 T5, PX 125 T5 Elestart is produced in 1985-99. Engine is Two stroke, Single cylinder,, displacement 123.4 cc 7.5 cub in , produces power 8.8 kW / 12 hp @ 6500 rpm and 13.1 kW / 1.34 kgf-m / 9.7 ft/lb @ 6250 rpm. Vespa PX125 T5, PX 125 T5 Elestart top speed is 106 km/h / 64 mph. Vespa PX125 T5, PX 125 T5 Elestart weighs 112 kg / 247 lbs. Vespa PX125 T5, PX 125 T5 Elestart has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | PX125 T5, PX 125 T5 Elestart |
| Years: | 1985-99 |
| Engine: | Two stroke, Single cylinder, |
| Capacity: | 123.4 cc 7.5 cub in |
| Bore x Stroke: | 52 x 55 mm |
| Carburetor: | Dell'Orto SI 24/24G . |
| Compression Ratio: | 11.3:1 |
| Cooling: | Air cooled, centrifugal fan |
| Fuel Mixture: | 1:20 |
| Spark Plug: | Bosch W3CC or Champion N2C |
| Ignition: | Flywheel alternator, with built in H.T. coil |
| Starting: | Kick start |
| Clutch: | Multiplate |
| Max Power: | 8.8 kW / 12 hp @ 6500 rpm |
| Max Torque: | 13.1 kW / 1.34 kgf-m / 9.7 ft/lb @ 6250 rpm |
| Transmission: | 4 Speed, grip-shift, constant mesh |
| Gears: | 1st 16.4 / 2nd 11.0 / 3rd 7.5 / 4th 5.8:1 |
| Final Drive: | Direct drive |
| Frame: | Pressed sheet steel, streamlined monocoque structure |
| Front Suspension: | Helical spring and double acting hydraulic dampers |
| Rear Suspension: | Helical spring and double acting hydraulic dampers |
| Front Brakes: | Cable operated, 125 mm expanding type drum brake |
| Rear Brakes: | Cable operated, 125 mm expanding type drum brake |
| Wheels: | Interchangeable |
| Front Tyre: | 3.5 x 10" |
| Rear Tyre: | 3.5 x 10" |
| Dimensions: | Length: 1820 mm / 71.7 in Width: 700 mm / 27.6 in Height: 1170 mm / 46.1 in |
| Wheelbase: | 1250 mm / 49.2 in |
| Ground Clearance: | 100 mm / 3.9 in |
| Dry Weight: | 112 kg / 247 lbs |
| Fuel Capacity: | 8 L / 2.1 US gal |
| Reserve: | 2.1 L / 0.55 US gal |
| Consumption average: | 2.7 L/100 km / 37 km/l / 87 US mpg |
| Top Speed: | 106 km/h / 64 mph |
| Standing 400 m / 437 yards: | 20.2 sec |
