Technical specifications
|
| Model: |
P 125 ETS |
| Years: |
1984-85 |
|
Production:
|
11 711 units
|
|
Engine:
|
Two strike, Single cylinder,
|
|
Capacity:
|
121.2 cc / 7.4 cub in
|
|
Bore x Stroke:
|
55 x 51 mm
|
|
Compression:
|
9.5:1
|
|
Carburetor:
|
Dell'Orto SHBC 20/20L
|
|
Cooling:
|
Air cooled, centrifugal fan
|
|
Fuel Mixture:
|
1:50
|
|
Ignition:
|
Electronic
|
|
Starting:
|
Kick start
|
|
Spark Plug:
|
NGK BR7HS
|
|
Battery:
|
12V AC
|
|
Clutch:
|
Wet, multiplate
|
|
Max Power:
|
6.2 kW / 8,6 hp @ 6000 rpm
|
|
Transmission:
|
4 Speed, grip-shift, constant mesh
|
|
Gear Ratios:
|
1st 14.74 / 2nd 19.80 / 3rd 7.06 / 4th 5.31:1
|
|
Final Drive:
|
Direct drive
|
|
Frame:
|
Pressed sheet steel, streamlined monocoque structure
|
|
Front Brakes:
|
150 mm drum
|
|
Rear Brakes:
|
150 mm drum
|
|
Wheels:
|
Interchangeable
|
|
Front Tyre:
|
3.0 x 10"
|
|
Rear Tyre:
|
3.0 x 10"
|
|
Dimensions:
|
Length: 1680 mm / 66.1 in Width: 700 mm / 27.6 in Height: 1070 mm / 42.1 in
|
|
Wheelbase:
|
1180 mm / 46.5 in
|
|
Ground Clearance:
|
252 mm / 9.9 in
|
|
Dry Weight:
|
85 kg / 187 lbs
|
|
Fuel Capacity:
|
6.0 L / 1.6 US gal
|
|
Reserve:
|
1.2 L / 0.3 US gal
|
|
Consumption Average:
|
2.1 L/100 km / 48 km/l / 111 US mpg
|
|
Top Speed:
|
97 km/h / 62 mph
|
