TVS Apache RR 310 (2019) technical specifications

TVS Apache RR 310 technical specifications

TVS Apache RR 310 is produced in 2019. Engine is Four stroke, single cylinder, reverse inclined, SOHC, 4 valves, displacement 312.2 cc / 19.1 cu in , produces power 25 kW / 34 hp @ 9700 rpm and 27.3 Nm / 20.1 lb-ft @ 7700 rpm. TVS Apache RR 310 wet weight is 169.5 kg / 374 lbs. TVS Apache RR 310 has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: Apache RR 310
Years: 2019
Engine: Four stroke, single cylinder, reverse inclined, SOHC, 4 valves
Capacity: 312.2 cc / 19.1 cu in
Bore x Stroke: 80 x 62.1 mm
Compression Ratio: 10.9:1
Cooling: Liquid Cooled
Intake Valve: 33.5 mm
Outlet Valve: 27.2 mm
Induction: Bosh electronic fuel injection, BMS-E2, closed-loop
Ignition: Dynamically controlled integrated high energy
Alternator: 330W
Battery: 12V, 8 Ah
Starting: Electric
Max Power: 25 kW / 34 hp @ 9700 rpm
Max Torque: 27.3 Nm / 20.1 lb-ft @ 7700 rpm
Clutch: Wet, multi-plate, RT slipper clutch
Transmission: 6-Speed, constant-mesh
Frame: Steel Trellis, split chiasis
Front Suspension: 41mm KYB inverted cartridge telescopic fork
Front Wheel Travel: 140 mm / 5.5 in
Rear Suspension: 2-arm aluminium die-cast swing-arm, mono tube floating piston gas assisted shock
Rear Wheel Travel: 131 mm / 5.5 in
Front Brakes: Single 300mm disc, 4 piston caliper, ABS
Rear Brakes: Single 240mm disc, single piston caliper, ABS
Wheels: 5-Spoke, light alloy die-cast
Rim Front: 3.0 x 17
Rim Rear: 4.0 x 17
Front Tyre: 110/70-R17 M/C 54H
Rear Tyre: 150/60-R17 M/C 66H
Dimensions: Length 2001 mm / 78.8 in Width 786 mm / 30.9 in Height 1135 mm / 44.7 in
Wheelbase: 1365 mm / 53.7 in
Seat Height: 810 mm / 32 in
Ground Clearance: 180 mm / 7 in
Wet Weight: 169.5 kg / 374 lbs
Fuel Capacity: 11 Litres / 2.9 US gal
