Triumph TT600 (2001) technical specifications

Triumph TT600 technical specifications

Triumph TT600 is produced in 2001. Engine is Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder., displacement 599 cc / 36.6 cu in , produces power 80.2 kW / 110 hp @ 12750 rpm and 68 Nm / 6.93 kg-m / 50.2 ft-lb @ 11000 rpm. Triumph TT600 top speed is 248 km/h / 154 mph. Triumph TT600 weighs 170 kg / 374 lbs. Triumph TT600 has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: TT600
Years: 2001
Engine: Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder.
Capacity: 599 cc / 36.6 cu in
Bore x Stroke: 68 x 41.3 mm
Cooling System: Liquid cooled
Compression Ratio: 12.5:1
Lubrication: Wet sump
Engine Oil: Synthetic, 15W/40
Induction: Multipoint sequential electronic fuel injection with forced air induction
Ignition: Digital
Spark Plug: NGK, CR9EK
Starting: Electric
Max Power: 80.2 kW / 110 hp @ 12750 rpm
Max Torque: 68 Nm / 6.93 kg-m / 50.2 ft-lb @ 11000 rpm
Clutch: Wet, multiple discs, cable operated
Transmission: 6 Speed
Final Drive: Chain
Frame: Aluminium, twin spar
Front Suspension: 43mm forks with dual rate springs and adjustable preload, compression and rebound damping
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Monoshock with adjustable preload, compression and rebound damping
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2x 310 mm Discs, 4 piston calipers
Rear Brakes: Single 220mm disc, 1 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 180/55 ZR17
Dimensions: Length 2060 mm / 81.1 in Width 665mm / 26.2 in Height 1150 mm / 45.3 in
Wheelbase: 1395mm / 54.9in
Seat Height: 810mm / 31.9in
Dry Weight: 170 kg / 374 lbs
Fuel Capacity: 18 Litres / 4.8 US gal / 4.0 Imp gal
Consumption Average: 5.4 L/100 km / 18.5 km/l / 43.5 US mpg / 52.3 Imp mpg
Standing ¼ Mile: 11.4 sec / 193 km/h / 120 mph
Top Speed: 248 km/h / 154 mph
