Triumph Tiger 800 XRx (2017-18) technical specifications

Triumph Tiger 800 XRx technical specifications

Triumph Tiger 800 XRx is produced in 2017-18. Engine is Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder., displacement 799 cc / 48.7 cub in , produces power 70.8 KW / 95 hp @ 9250 rpm and 79 Nm / 8.1 kgf-m / 58 ft.lb @ 7950 rpm. Triumph Tiger 800 XRx weighs 199 kg / 438.7 lbs. Triumph Tiger 800 XRx has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Tiger 800 XRx
Years: 2017-18
Engine: Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder.
Capacity: 799 cc / 48.7 cub in
Bore x Stroke: 74 x 61.9 mm
Compression Ratio: 11.3:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Oil Capacity: 3.7 L / 0.98 US gal / 0.81 Imp gal
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital CDI
Starting: Electric
Exhaust: Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Clutch: Wet, multi-plate
Max Power: 70.8 KW / 95 hp @ 9250 rpm
Max Torque: 79 Nm / 8.1 kgf-m / 58 ft.lb @ 7950 rpm
Transmission: 6 Speed
Final Drive: Chain, O-ring
Frame: Tubular steel trellis frame, swingarm: twin-sided, cast aluminum alloy
Front Suspension: Showa 43mm upside down forks
Front Wheel Travel: 180 mm / 7.1 in
Rear Suspension: Showa monoshock with hydraulically adjustable preload
Rear Wheel Travel: 170 mm / 6.7 in
Front Brakes: 2 x 308 mm floating discs, Nissin 2-piston sliding caliper, switchable ABS
Rear Brakes: Single 255 mm disc, Nissin single-piston sliding caliper, switchable ABS
Front Wheel: Cast aluminium, 10-spoke, 19 x 2.50
Rear Wheel: Cast aluminium, 10-spoke, 17 x 4.25
Front Tyre: 100/90-19
Rear Tyre: 150/70 R17
Rake: 23.9°
Trail: 92.4 mm / 3.64 in
Dimensions: Length 2215 mm / 87.1in Width 795 mm / 31.3 in (with handlebars) Height 1350 mm / 53.1 in (without mirrors)
Wheelbase: 1530 mm / 60.2 in
Seat Height: 810 mm - 830 mm / 31.8 in- 32.6 in adjustable
Dry Weight: 199 kg / 438.7 lbs
Fuel Capacity: 19 Litres / 5.0 US gal / 4.2 Imp gal
