Triumph Thunderbird (2017-18) technical specifications

Triumph Thunderbird is produced in 2017-18. Engine is Four stroke, parallel twin, DOHC, 4 valves per cylinder, 270° firing interval., displacement 1597 cc / 97.5 cub in , produces power 64 kW / 86 hp @ 4850 rpm and 146 Nm / 14.9 kgf-m / 107.7 ft-lb @ 2750rpm. Triumph Thunderbird weighs 308 kg / 679 lbs. Triumph Thunderbird has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Thunderbird
Years:	2017-18
Engine:	Four stroke, parallel twin, DOHC, 4 valves per cylinder, 270° firing interval.
Capacity:	1597 cc / 97.5 cub in
Bore x Stroke:	103.8 x 94.3 mm
Cooling System:	Liquid cooled
Compression Ratio:	9.7:1
Oil Capacity:	4.2 L / 1.1 US gal .0.92 Imp gal
Exhaust:	Chromed twin-skin stainless steel 2 into 1 into 2 exhaust system with chrome plated silencers
Lubrication:	Wet sump
Induction:	Multipoint sequential electronic fuel injection with SAI , progressive linkage on throttle
Ignition:	Digital inductive type via electronic engine management
Starting:	Electric
Max Power:	64 kW / 86 hp @ 4850 rpm
Max Torque:	146 Nm / 14.9 kgf-m / 107.7 ft-lb @ 2750rpm
Clutch:	Wet, multi-plate
Transmission:	6 Speed
Final Drive:	Toothed belt
Gear Ratio:	1st 2.9875 / 2nd 1.958 / 3rd 1.536 / 4th 1.219 / 5th 1.029 / 6th 0.909:1
Frame:	Tubular steel, twin spine, swingarm twin sided, steel
Front Suspension:	Showa 47mm forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Showa chromed spring twin shocks with 5 position adjustable preload.
Rear Wheel Travel:	95 mm / 3.7 in
Front Brakes:	2 x 310 mm floating discs, Nissin 4 piston fixed calipers, ABS
Rear Brakes:	Single 310 mm fixed disc, Brembo 2 piston floating caliper, ABS
Front Wheel:	Cast aluminium alloy 5-spoke 19 x 3.5 in
Rear Wheel:	Cast aluminium alloy 5-spoke 17 x 6 in
Front Tyre:	120/70 R19
Rear Tyre:	200/50 R17
Rake:	32°
Trail:	151 mm / 5.9 in
Dimensions:	Length 2340 mm / 92.1 in Width 800 mm / 34.6 in (Handlebars) Height 1120 mm / 44.1 in
Wheelbase:	1615 mm / 63.5 in
Seat Height:	702 mm / 27.6 in
Dry Weight:	308 kg / 679 lbs
Wet Weight:	339 kg / 747 lbs
Fuel Capacity:	22 Litres / 5.8 gal
