2020 Triumph Street Triple S / A2 technical specifications

Triumph Street Triple S / A2 technical specifications

Technical specifications

Model: Street Triple S / A2
Years: 2020
Engine: Four stroke,  in-line 3-cylinder, DOHC, 4 valve percylinder
Capacity: 660 cc / 40.27 cu-in
Bore x Stroke: 76.0 x48.5 mm
Cooling System: Liquid-cooled
Compression Ratio: 12.1:1
Lubrication: Wet sump
Induction: Multipoint sequentialelectronic fuel injection with SAI, Electronic throttlecontrol
Exhaust: Stainless steel 3 into1 exhaust system low single sided stainless steelsilencer
Ignition : Digital - inductive type
Starting: Electric
Max Power: 35kW /46.9 hp / 47.6 PS @ 9,000 rpm
Max Power Derestricted: 70kW / 93.8 hp / 95.2PS @ 11,250 rpm
Max Torque: 60 Nm / 44.2 lb-ft @5,250 rpm
Max Torque Derestricted: 66 Nm / 48.6 lb-ft @9,250 rpm
Clutch: Wet, multi-plate
Transmission : 6 Speed
Final Drive: X ringchain
Frame: Front - Aluminium beamtwin sparRear - 2 piece high pressure die cast
Swingarm: Twin-sided, cast aluminium alloy
Front Suspension: Showa 41mm upside downforks
Front Wheel Travel: 110 mm / 4.3 in
Rear Suspension: Showa piggybackreservoir monoshock, adjustable preload
Rear Wheel Travel: 124 mm / 4.9 in
Front Brakes: 2 x 310mm floating discs, Nissin 2-pistonsliding calipers
Rear Brakes: Single 220mm disc, Brembo single pistoncaliper
ABS: Switchable ABS
Front Wheels: Cast aluminium alloy5-spoke 17 x 3.5 in
Rear Wheels: Cast aluminium alloy5-spoke 17 x 5.5 in
Front Tyre: 120/70 ZR17 PirelliDiablo Rosso III
Rear Tyre: 180/55 ZR17 PirelliDiablo Rosso III
Rake: 24.8º
Trail: 103.4 mm /  4.0in
Dimensions: Width     765mm / 30.1 in - with handlebarsHeight 1060 mm / 41.7 in - without mirrors
Wheelbase: 1410 mm / 55.5 in
Seat Height: 810 mm /  31.8 in
Dry Weight: 168 Kg /  370.3lbs
Fuel Capacity : 17.4 Litres / 4.6 US gal / 3.8 Impgal
