Moto-Data

Triumph Street Triple RS (2020) technical specifications

Triumph Street Triple RS technical specifications

Triumph Street Triple RS is produced in 2020. Engine is Four stroke, in-line 3-cylinder, DOHC, 4 valve per cylinder, displacement 765 cc / 46.6 cu-in , produces power 121.3 hp / 123 PS / 90 kW @ 11,750 rpm and 79 Nm / 58.3 lb-ft @ 9,350 rpm. Triumph Street Triple RS weighs 166 kg / 366 lbs. Triumph Street Triple RS has 10 photos.

Technical specifications

+ Add to 'Compare list'
Model: Street Triple RS
Years: 2020
Engine: Four stroke, in-line 3-cylinder, DOHC, 4 valve per cylinder
Capacity: 765 cc / 46.6 cu-in
Bore x Stroke: 78 x 53.4 mm
Cooling System: Liquid-cooled
Compression Ratio: 12.54:1
Lubrication: Wet sump
Induction: Multipoint sequential electronic fuel injection with SAI. Electronic throttle control
Exhaust: Stainless steel 3 into 1 exhaust system low single sided stainless steel silencer
Emission: Euro 5
Ignition: Digital - inductive type
Starting: Electric
Max Power: 121.3 hp / 123 PS / 90 kW @ 11,750 rpm
Max Torque: 79 Nm / 58.3 lb-ft @ 9,350 rpm
Clutch: Wet, multi-plate, slip-assisted
Transmission: 6 Speed with Triumph Shift Assist
Final Drive: X ring chain
Frame: Front - Aluminum beam twin spar Rear - 2 piece high pressure die cast
Swingarm: Twin-sided, cast aluminum alloy
Front Suspension: Showa 41 mm upside down big piston forks (BPF), Adjustable compression damping, rebound damping and preload adjustment
Front Wheel Travel: 115 mm / 4.5 in
Rear Suspension: Öhlins STX40 fully-adjustable piggyback reservoir RSU
Rear Wheel Travel: 131 mm / 5.2 in
Front Brakes: 2 x 310mm floating discs, Brembo M50 4-piston monobloc calipers
Rear Brakes: Single 220mm disc, Brembo single-piston caliper
ABS: Adjustable ABS
Wheels: 5-spoke cast aluminum alloy
Front Wheels: 3.5 x 17
Rear Wheels: 5.5 x 17
Front Tyre: 120/70 ZR17 Pirelli Diablo Supercorsa SP V3
Rear Tyre: 180/55 ZR17 Pirelli Diablo Supercorsa SP V3
Rake: 23.9º
Trail: 100 mm / 3.9 in
Dimensions: Width 775 mm / 30.5 in - with handlebars Height 1085 mm / 42.7 in - without mirrors
Wheelbase: 1405 mm / 55.3 in
Seat Height: 825 mm / 32.5 in
Dry Weight: 166 kg / 366 lbs
Fuel Capacity: 17.4 Litres / 4.6 US gal / 3.8 Imp gal
