Triumph Speed Triple S (2019) technical specifications

Triumph Speed Triple S technical specifications

Triumph Speed Triple S is produced in 2019. Engine is Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder, displacement 1050 cc / 64.1 cub in , produces power 148 hp / 110 kW @ 10500 rpm and 117 Nm / 86.2 lb-ft @ 7150 rpm. Triumph Speed Triple S weighs 192 kg / 423.2 lbs. Triumph Speed Triple S has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Speed Triple S
Years: 2019
Engine: Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Capacity: 1050 cc / 64.1 cub in
Bore x Stroke: 79 x 71.4 mm
Cooling System: Liquid-cooled
Compression Ratio: 12.92:1
Induction: Multipoint sequential electronic fuel injection with SAI
Oil Capacity: 3.8 L / 1.0 US gal / 0.8 Imp gal
Exhaust: Stainless Steel 3 into 1 into 2 high level stainless steel silencers
Ignition: Electronic
Starting: Electric
Max Power: 148 hp / 110 kW @ 10500 rpm
Max Torque: 117 Nm / 86.2 lb-ft @ 7150 rpm
Clutch: Wet, multi-plate slip assist clutch
Transmission: 6 Speed
Final Drive: X ring chain
Frame: Aluminium beam twin-spar, single sided swingarm, aluminium alloy with eccentric chain adjuster
Front Suspension: Showa 43 mm upside down forks with adjustable preload, rebound and compression damping
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Showa monoshock with adjustable preload, rebound and compression damping
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x 320mm floating discs, Brembo 4 piston monobloc radial calipers, switchable ABS
Rear Brakes: Single 255mm disc, Nissin 2 piston sliding caliper, switchable ABS
Front Wheel: Cast aluminium alloy multi spoke 17 x 3.5 in
Rear Wheel: Cast aluminium alloy multi spoke 17 x 6.0 in
Front Tyre: 120/70 ZR17
Rear Tyre: 190/55 ZR17
Rake: 22.9°
Trail: 91.3 mm / 3.6 in
Dimensions: Width 775 mm / 30.5 in Height 1070 mm / 42.1 in
Wheelbase: 1445 mm / 56.8 in
Seat Height: 825 mm / 32.4 in
Dry Weight: 192 kg / 423.2 lbs
Fuel Capacity: 15.5 Litres / 4.1 US gal / 3.4 Imp gal
Instruments: Full-colour 5" TFT instruments
