Triumph Speed Triple (2006) technical specifications

Triumph Speed Triple technical specifications

Triumph Speed Triple is produced in 2006. Engine is Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder, displacement 1050 cc / 64.07 cu-in , produces power 94.9 Nm / 131 hp @ 9100 rpm and 105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm. Triumph Speed Triple top speed is 248.7 km/h / 154.5 in. Triumph Speed Triple weighs 189 kg / 416.7 lbs. Triumph Speed Triple has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Speed Triple
Years: 2006
Engine: Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder
Capacity: 1050 cc / 64.07 cu-in
Bore x Stroke: 79 x 71.4 mm
Cooling System: Liquid-cooled
Compression Ratio: 12.0:1
Lubrication: Wet sump
Engine Oil: 10W/40 Synthetic
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital inductive type
Spark Plug: NGK, CR9EK
Starting: Electric
Max Power: 94.9 Nm / 131 hp @ 9100 rpm
Max Torque: 105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm
Clutch: Wet, multi-plate
Transmission: 6 Speed
Final Drive: Chain
Frame: Tubular, fabricated aluminum alloy, perimeter
Front Suspension: 45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping
Front Wheel Travel: 120 mm / 4.7
Rear Suspension: Monoshock with adjustable preload, compression and rebound damping
Rear Wheel Travel: 140 mm / 5.7 in
Front Brakes: 2 x 320 mm Discs, 4 piston calipers
Rear Brakes: Single 220 mm disc, 2 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 190/50 ZR17
Rake: 24°
Trail: 84 mm / 3.3 in
Dimensions: Length 2115 mm / 83.3 in Width 780 mm / 30.7 in Height 1250 mm / 49.2 in
Wheelbase: 1429 mm / 56.3 in
Seat Height: 815 mm / 32.1 in
Dry Weight: 189 kg / 416.7 lbs
Fuel Capacity: 18 Litres / 4.89 gal
Standing ¼ Mile: 11.8 sec
Top Speed: 248.7 km/h / 154.5 in
