Triumph Speed Triple 15th Anniversary Edition (2009) technical specifications

Triumph Speed Triple 15th Anniversary Edition technical specifications

Triumph Speed Triple 15th Anniversary Edition is produced in 2009. Engine is Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder, displacement 1050 cc / 64.07 cu-in , produces power 94.9 Nm / 131 hp @ 9100 rpm and 105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm. Triumph Speed Triple 15th Anniversary Edition top speed is 248.7 km/h / 154.5 in. Triumph Speed Triple 15th Anniversary Edition weighs 189 kg / 416.7 lbs. Triumph Speed Triple 15th Anniversary Edition has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Speed Triple 15th Anniversary Edition
Years: 2009
Engine: Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder
Capacity: 1050 cc / 64.07 cu-in
Bore x Stroke: 79 x 71.4 mm
Cooling System: Liquid-cooled
Compression Ratio: 12.0:1
Lubrication: Wet sump
Engine Oil: 10W/40 Synthetic
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital inductive type
Spark Plug: NGK, CR9EK
Starting: Electric
Max Power: 94.9 Nm / 131 hp @ 9100 rpm
Max Torque: 105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm
Clutch: Wet, multi-plate
Transmission: 6 Speed
Final Drive: Chain
Frame: Tubular, fabricated aluminum alloy, perimeter
Front Suspension: 45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping
Front Wheel Travel: 120 mm / 4.7
Rear Suspension: Monoshock with adjustable preload, compression and rebound damping
Rear Wheel Travel: 140 mm / 5.7 in
Front Brakes: 2 x 320 mm Discs, 4 piston calipers
Rear Brakes: Single 220 mm disc, 2 piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 190/50 ZR17
Rake: 24°
Trail: 84 mm / 3.3 in
Dimensions: Length 2115 mm / 83.3 in Width 780 mm / 30.7 in Height 1250 mm / 49.2 in
Wheelbase: 1429 mm / 56.3 in
Seat Height: 815 mm / 32.1 in
Dry Weight: 189 kg / 416.7 lbs
Fuel Capacity: 18 Litres / 4.89 gal
Standing ¼ Mile: 11.8 sec
Top Speed: 248.7 km/h / 154.5 in
