Triumph Scrambler 1200 XE (2026) technical specifications

Triumph Scrambler 1200 XE technical specifications

Triumph Scrambler 1200 XE is produced in 2026. Engine is Four stroke, 270? crank angle parallel twin, SOHC, 4 valves per cylinder, displacement 1197 cc / 73.0 cu-in , produces power 89 hp / 66.2 kW @ 7300 rpm and 110 Nm / 81.1 lb-ft @ 4500 rpm. Triumph Scrambler 1200 XE wet weight is 227 kg / 500 lbs. Triumph Scrambler 1200 XE has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Scrambler 1200 XE
Years: 2026
Engine: Four stroke, 270? crank angle parallel twin, SOHC, 4 valves per cylinder
Capacity: 1197 cc / 73.0 cu-in
Bore x Stroke: 97.6 x 80.0 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Exhaust: Single skin, brushed 2-into-1 exhaust system with high-level silencer
Emission: Euro 5+
Lubrication: Wet sump
Induction: Multipoint sequential electronic fuel injection, ride by wire
Ignition: Digital ? inductive type
Starting: Electric
Max Power: 89 hp / 66.2 kW @ 7300 rpm
Max Torque: 110 Nm / 81.1 lb-ft @ 4500 rpm
Clutch: Wet, multi-plate assist clutch
Transmission: 6 Speed
Final Drive: O ring chain
Frame: Tubular steel with with steel cradles, twin-sided aluminum swingarm
Front Suspension: Showa ?47mm Upside-down BP-SFF forks, adjustable for preload, compression and rebound damping.
Front Wheel Travel: 249 mm / 9.8 in
Rear Suspension: ?hlins twin RSU?s with piggy-back reservoirs and twin springs. Adjustable for preload, compression and rebound damping
Rear Wheel Travel: 249 mm / 9.8 in
Front Brakes: Twin 320mm discs, Brembo 4 piston M4.30 radial monoblock calipers, OC-ABS
Rear Brakes: Single 255mm disc, single piston floating Nissin caliper, OC-ABS
ABS: Cornering aware ABS
Wheel Front: 36-spoke 21 x 2.15 in, aluminum rims
Wheel Rear: 32-spoke 17 x 4.25 in, aluminum rims
Front Tyre: 90/90-21
Rear Tyre: 150/70 R17
Rake: 26.9?
Trail: 129 mm / 5.07 in
Dimensions: Length 2325 mm / 91.5 in Width 905 mm / 35.6 in with handlebars Height 1250 mm / 49.2 in without mirrors
Wheelbase: 1570 mm / 61.8 in
Seat Height: 870 mm / 34.3 in
Wet Weight: 227 kg / 500 lbs
Fuel Capacity: 16 Litres / 4.2US gal
Instruments: Multi-function instruments with colour TFT screen
