Triumph Bonneville T100 Bud Ekins Edition (2020) technical specifications

Triumph Bonneville T100 Bud Ekins Edition technical specifications

Triumph Bonneville T100 Bud Ekins Edition is produced in 2020. Engine is Four stroke, 270° Crank angle parallel twin, SOHC, 8 valves, displacement 900 cc / 54.9 cu in , produces power 40.5 kW / 54 hp @ 5900 rpm and 80 Nm / 8.16 kgf-m / 59 ft-lb @ 3230 rpm. Triumph Bonneville T100 Bud Ekins Edition weighs 213 kg / 470 lbs. Triumph Bonneville T100 Bud Ekins Edition has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: Bonneville T100 Bud Ekins Edition
Years: 2020
Engine: Four stroke, 270° Crank angle parallel twin, SOHC, 8 valves
Capacity: 900 cc / 54.9 cu in
Bore x Stroke: 84.6 x 80 mm
Cooling System: Liquid cooled
Compression Ratio: 10.55:1
Lubrication: Wet sump
Engine Oil: Synthetic, 15W/50
Exhaust: Chromed 2 into 2 exhaust system with twin silencers
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital
Starting: Electric
Max Power: 40.5 kW / 54 hp @ 5900 rpm
Max Torque: 80 Nm / 8.16 kgf-m / 59 ft-lb @ 3230 rpm
Clutch: Wet, multi plate assist, cable operated
Transmission: 5 Speed
Final Drive: Chain, X-ring
Frame: Tubular steel cradle
Front Suspension: 41mm Kayaba cartridge forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Twin sided swingarm, Kayaba spring twin shocks with adjustable preload
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: Single 310 mm disc, 2 piston floating calipers, Nissin
Rear Brakes: Single 255 mm disc, 2 piston floating calipers, Nissin
ABS: Standard
Wheels Front: 32 Spokes, 18 x 2.75 in
Wheels Rear: 32 Spokes, 17 x 4.25 in
Front Tyre: 100/90-R18
Rear Tyre: 150/70-R17
Rake: 25.5°
Trail: 104 mm / 4.1 in
Dimensions: Width 715 mm / 28.1 in Height 1100 mm / 43.3 in
Wheelbase: 1450 mm / 57.1 in
Seat Height: 790 mm / 31.1 in
Dry Weight: 213 kg / 470 lbs
Fuel Capacity: 14.5 Litres / 3.8 US gal / 3.2 Imp gal
