Triumph Bonneville Speedmaster (2018) technical specifications

Triumph Bonneville Speedmaster technical specifications

Triumph Bonneville Speedmaster is produced in 2018. Engine is Four stoke, parallel twin, 270o crank, SOHC, displacement 1198 cc / 73.1 cu in , produces power 57.4 kW / 77 hp @ 6550 rpm and 106 Nm / 10.7 kgf-m / 77.4 lb-ft @ 3100 rpm. Triumph Bonneville Speedmaster weighs 245.5kg / 540 lbs. Triumph Bonneville Speedmaster has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: Bonneville Speedmaster
Years: 2018
Engine: Four stoke, parallel twin, 270o crank, SOHC
Capacity: 1198 cc / 73.1 cu in
Bore x Stroke: 97.6 x 80 mm
Compression Ratio: 10.0:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Exhaust: Straight line stainless steel twin-skin slash cut twin stubby silencers
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital
Starting: Electric
Max Power: 57.4 kW / 77 hp @ 6550 rpm
Max Torque: 106 Nm / 10.7 kgf-m / 77.4 lb-ft @ 3100 rpm
Clutch: Wet, multi-plate
Transmission: 6-Speed
Final Drive: Chain, X-ring
Frame: Dual tubular steel cradle
Front Suspension: 41 mm Kayaba fork
Front Wheel Travel: 90 mm / 3.5 in
Rear Suspension: Kayaba twin shocks with adjustable preload
Rear Wheel Travel: 73 mm / 2.8 in
Front Brakes: 2 x 310 mm Disc, 2 piston calipers, ABS
Rear Brakes: Single 255 mm disc, 2 piston caliper, ABS
Wheels: Wire 32-spoke, steel rims
Front Tyre: 130/90-16
Rear Tyre: 150/80-16
Seat Height: 705 mm / 27.7 in
Dry Weight: 245.5kg / 540 lbs
Fuel Capacity: 12 Litres / 3.17 US gal
