SYM Mio 50 (2014) technical specifications

SYM Mio 50 is produced in 2014. Engine is Single cylinder, 4-stroke, 2-Valve, SOHC, displacement 49.5 cc / 3.0 cub in. , produces power 2.8 kW / 3.8 hp @ 8000 rpm and 3.73 Nm / 0.38 kgf-m / 2.75 ft/lbs @ 6500 rpm. SYM Mio 50 top speed is 45 km/h / 28 mph. SYM Mio 50 wet weight is 85 kg / 187 lbs. SYM Mio 50 has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Mio 50
Years:	2014
Engine:	Single cylinder, 4-stroke, 2-Valve, SOHC
Capacity:	49.5 cc / 3.0 cub in.
Bore and Stroke:	37 x 46 mm
Cooling System:	Air cooled, forced
Compression Ratio:	12.6:1
Lubrication:	Dry sump
Exhaust:	Single
Fuel System:	Carburetor
Induction:	Electronic
Ignition:	CDI
Battery:	12V 6 Ah
Starting:	Electric & kick
Max Power:	2.8 kW / 3.8 hp @ 8000 rpm
Max Torque:	3.73 Nm / 0.38 kgf-m / 2.75 ft/lbs @ 6500 rpm
Clutch:	Centrifugal
Transmission:	CVT
Final Drive:	Belt
Frame:	Split steel tube
Front Suspension:	Telescopic fork
Rear Suspension:	Twin sided swing arm
Front Brakes:	Hydraulic disc, 160 mm
Rear Brakes:	Drum, 95 mm
Wheels:	Aluminium
Front Tyre:	90/90-10 50J
Rear Tyre:	90/90-10 50J
Dimensions:	Length: 1720 mm / 67.7 in. Width: 720 mm / 28.3 in. Height: 1090 mm / 42.9 in.
Wheelbase:	1180 mm / 46.5 in.
Ground Clearance:	95 mm / 3.7 in.
Seat Height:	720 mm / 28.3 in.
Wet Weight:	85 kg / 187 lbs
Fuel Capacity:	4.8 L / 1.3 US gal
Average Fuel Consumption:	1.5 L/100km / 65 km/l / 153 US mpg
Top Speed:	45 km/h / 28 mph
Climbing Capacity:	20°
Colours:	Matt white/matt coffee, Golden brown, Black/red, Black/white, White, White/orange, White/red, White/pink
Source:	Philadelphia Scooters
