SYM Jet V 125 (2014) technical specifications

SYM Jet V 125 technical specifications

SYM Jet V 125 is produced in 2014. Engine is Single cylinder, 4-stroke, 2-valve, SOHC, displacement 124.6 cc / 7.6 cub in. , produces power 7.2 kW / 9.8 hp @ 7500 rpm and 9.9 Nm / 1.01 kgf-m / 7.30 ft/lbs @ 6000 rpm. SYM Jet V 125 top speed is 93 km/h / 58 mph. SYM Jet V 125 wet weight is 108 kg / 238 lbs. SYM Jet V 125 has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Jet V 125
Years: 2014
Engine: Single cylinder, 4-stroke, 2-valve, SOHC
Capacity: 124.6 cc / 7.6 cub in.
Cooling System: Air cooled, forced
Compression Ratio: 11.2:1
Engine Oil Capacity: 1.0 L / 2.1 US pints
Transmission Oil Capacity: 0.11 L / 0.23 US pints
Lubrication: Dry sump
Exhaust: Single
Fuel System: Carburetor (CV)
Induction: Electronic
Ignition: CDI
Spark Plug: NGK CR7HSA
Battery: 12V, 8.6 Ah
Starting: Electric & kick
Max Power: 7.2 kW / 9.8 hp @ 7500 rpm
Max Torque: 9.9 Nm / 1.01 kgf-m / 7.30 ft/lbs @ 6000 rpm
Clutch: Centrifugal
Transmission: CVT
Final Drive: Belt
Frame: Steel, monocuna split steel tube
Front Suspension: Telescopic fork
Rear Suspension: Twin sided swing arm
Front Brakes: Disc, 180 mm
Rear Brakes: Drum, 130 mm
Wheels: Aluminium alloy
Front Rim: MT 2.50 x 10 in.
Front Tyre: 100/90-10 56J
Rear Rim: MT 2.50 x 10 in.
Rear Tyre: 100/90-10 56J
Dimensions: Length: 1820 mm / 71.7 in. Width: 680 mm / 26.8 in. Height: 1090 mm / 42.9 in.
Wheelbase: 1260 mm / 49.6 in.
Ground Clearance: 110 mm / 4.3 in.
Seat Height: 760 mm / 29.9 in.
Wet Weight: 108 kg / 238 lbs
Fuel Capacity: 5.5 L / 1.5 US gal
Average Fuel Consumption: 2.1 L/100km / 47 km/l 110 US mpg
Top Speed: 93 km/h / 58 mph
Climbing Capacity: 28°
Colours: Black, White, Grey
