Technical specifications
|
| Model: |
Jet Sport X 50 |
| Years: |
2014 |
|
Engine:
|
Single cylinder, 2-stroke
|
|
Capacity:
|
49.5 cc / 3.0 cub in.
|
|
Bore and Stroke:
|
39 mm / 41.4 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
7.2:1
|
|
Engine Oil Capacity:
|
1.2 L / 2.5 US pints
|
|
Transmission Oil Capacity:
|
0.12 L / 0.25 US pints
|
|
Transmission Oil:
|
Winter: SAE 85W-90 Summer: SAE 85W 140
|
|
Lubrication:
|
Dry sump
|
|
Exhaust:
|
Single
|
|
Fuel System:
|
Separate, forced oil supply
|
|
Induction:
|
Electronic
|
|
Ignition:
|
CDI
|
|
Spark Plug:
|
BR 8HSA
|
|
Battery:
|
12V, 6 Ah
|
|
Starting:
|
Electric & kick
|
|
Max Power:
|
2.6 kW / 3.5 hp @ 6000 rpm
|
|
Max Torque:
|
4.2 Nm / 0.43 kgf-m / 3.1 ft/lbs @ 5500 rpm
|
|
Clutch:
|
Centrifugal, dry
|
|
Transmission:
|
CVT
|
|
Final Drive:
|
Belt
|
|
Frame:
|
Steel, monocuna split steel tube
|
|
Front Suspension:
|
Telescopic fork
|
|
Rear Suspension:
|
Twin sided swing arm
|
|
Front Brakes:
|
Hydraulic disc, 190 mm
|
|
Rear Brakes:
|
Drum, 110 mm / Disc 160 mm
|
|
Wheels:
|
Aluminium
|
|
Front Tyre:
|
120/70-12 tubeless
|
|
Rear Tyre:
|
130/70-12 tubeless
|
|
Dimensions:
|
Length: 1840 mm / 72.4 in. Width: 690 mm / 27.2 in. Height: 1120 mm / 44.1 in.
|
|
Wheelbase:
|
1275 mm / 52.2 in.
|
|
Dry Weight:
|
98 kg / 216 lbs
|
|
Wet Weight:
|
109 kg / 240 lbs
|
|
Fuel Capacity:
|
6.3 L / 1.7 US gal
|
|
Average Fuel Consumption:
|
2.3 L/100km / 43 km/l 101 US mpg
|
|
Top Speed:
|
77 km/h / 48 mph
|
|
Colours:
|
Black, Red, White, Orange
|
|
