Technical specifications
|
| Model: |
VS 700GL Intruder |
| Years: |
1986 |
|
Engine:
|
Four stroke, 45°V-twin, SOHC, 4 valves per cylinder
|
|
Capacity:
|
699 cc / 42.7 cu in
|
|
Cooling System:
|
Liquid cooled
|
|
Induction:
|
2 x 34 mm Mikuni CV carburetors
|
|
Ignition:
|
Electronic
|
|
Starting:
|
Electric
|
|
Max Power:
|
41.0 kW / 55 hp @ 7500 rpm
|
|
Max Power (at rear wheel):
|
36.6 kW / 49.1 hp @ 7250 rpm
|
|
Max Torque:
|
55.9 Nm / 5.7 kgf-m / 41.2 lb-ft @ 5000 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Shaft
|
|
Front Suspension:
|
Telescopic air assisted fork
|
|
Rear Suspension:
|
Dual coil spring oil damped shocks, 5-way adjustable preload.
|
|
Front Brakes:
|
Single 280 mm disc
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
100/90 H19
|
|
Rear Tyre:
|
140/90 H15
|
|
Dry Weight:
|
206 kg / 454 lbs
|
|
Fuel Capacity:
|
12 Litres / 3.2 US gal / 2.6 Imp gal
|
