Technical specifications
|
| Model: |
VL 250LC Intruder |
| Years: |
2005-11 |
|
Engine:
|
Four stroke, 65° V-Twin, SOHC, 3 valves per cylinder
|
|
Capacity:
|
248 cc / 15.1 cu in
|
|
Bore x Stroke:
|
52 x 58.5 mm
|
|
Compression Ratio:
|
10.5:1
|
|
Cooling System:
|
Air cooled
|
|
Lubrication System:
|
Wet sump
|
|
Induction:
|
BDS26
|
|
Ignition:
|
Full transistor system
|
|
Starting:
|
Electric
|
|
Max Power:
|
17.5 kW / 24 hp @ 8500 rpm
|
|
Max Torque:
|
23 Nm / 2.3 kgf-m @ 6000 rpm
|
|
Clutch:
|
Wet, multi-plate
|
|
Transmission:
|
5 Speed, constant mesh
|
|
Final Drive:
|
Chain
|
|
Primary Reduction:
|
3.173:1
|
|
Gear Ratios:
|
1st 2.636 / 2nd 1.647 / 3rd 1.217 / 4th 0.952 / 5th 0.818:1
|
|
Final Reduction:
|
2.866:1
|
|
Frame:
|
Semi-double cradle
|
|
Rake:
|
31o
|
|
Trail:
|
121 mm / 4.8 in
|
|
Front Suspension:
|
Telescopic fork, 37 mm, oil/coil damped
|
|
Rear Suspension:
|
Twin shock, coil springs, 5 way adjustable
|
|
Front Brakes:
|
Single 275 mm disc, 1 piston caliper
|
|
Rear Brakes:
|
130 mm Drum
|
|
Front Tyre:
|
90/90-17
|
|
Rear Tyre:
|
150/80-15
|
|
Dimensions:
|
Length: 2240 mm / 88.2 in Width: 880 mm / 34.6 in Height: 1110 mm / 43.7 in
|
|
Wheelbase:
|
1520 mm / 59.8 in
|
|
Ground Clearance:
|
150 mm / 5.9 in
|
|
Seat Height:
|
685 mm / 27.0 in
|
|
Dry Weight:
|
143 kg / 315 lbs
|
|
Wet Weight:
|
159 kg / 350 lbs
|
|
Fuel Capacity:
|
12 Litres / 3.2 US gal / 2.6 Imp gal
|
|
