Suzuki TS 185ER (2000-05) technical specifications
Suzuki TS 185ER is produced in 2000-05. Engine is Two stroke, single cylinder, aluminium, power reed walve, displacement 183 cc / 11.2 cu in , produces power 13.4 kW / 18 hp @ 7000 rpm and 18.6 Nm / 1.9 kgf-m / 13.7 lb-ft @ 6500 rpm. Suzuki TS 185ER weighs 102 kg / 225 lbs. Suzuki TS 185ER has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | TS 185ER |
| Years: | 2000-05 |
| Engine: | Two stroke, single cylinder, aluminium, power reed walve |
| Capacity: | 183 cc / 11.2 cu in |
| Bore x Stroke: | 64 х 57 mm |
| Compression Ratio: | 6.0:1 |
| Cooling System: | Air cooled |
| Lubrication System: | Suzuki CCIS |
| Induction: | Mikuni VN29 carburetor |
| Ignition: | CDI |
| Starting: | Kick |
| Max Power: | 13.4 kW / 18 hp @ 7000 rpm |
| Max Torque: | 18.6 Nm / 1.9 kgf-m / 13.7 lb-ft @ 6500 rpm |
| Clutch: | Wet, multiplate |
| Transmission: | 5 Speed, constant mesh |
| Final Drive: | Chain |
| Front Suspension: | Telescopic fork, oil-dampened, 3-way adjustable |
| Rear Suspension: | Swinging arm, dual shocks, coil springs, oil-dampened, spring preload 5-way adjustable |
| Front Brakes: | Drum, internal expanding |
| Rear Brakes: | Drum, internal expanding |
| Front Tyre: | 2.75-21 4P, tube type |
| Rear Tyre: | 4.10-18 4P, tube type |
| Dimensions: | Length: 2160 mm / 85.0 in Width: 860 mm / 33.9 in Height: 1125 mm / 44.3 in |
| Wheelbase: | 1375 mm / 54.1 in |
| Ground Clearance: | 255 mm / 10.0 in |
| Seat Height: | 835 mm / 32.9 in |
| Dry Weight: | 102 kg / 225 lbs |
| Oil Capacity: | 1.2 Litres / 2.5 US pt / 2.1 Imp pt |
| Fuel Capacity: | 7.0 Litres / 1.8 US gal / 1.5 Imp gal |
