Suzuki SV 650X (2019) technical specifications

Suzuki SV 650X is produced in 2019. Engine is Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder, displacement 645 cc / 39.3 cu in , produces power 56 kW / 75 hp @ 8500 rpm and 64 Nm / 6.5 kgf-m / 47.2 lb-ft @ 8100 rpm. Suzuki SV 650X wet weight is 196 kg / 432.0 lbs. Suzuki SV 650X has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	SV 650X
Years:	2019
Engine:	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder
Capacity:	645 cc / 39.3 cu in
Bore x Stroke:	81 x 62.6 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.2:1
Lubrication:	Wet sump
Induction:	Suzuki fuel injection with SDTV
Ignition:	Electronic ignition (Transistorized)
Starting:	Electric
Max Power:	56 kW / 75 hp @ 8500 rpm
Max Torque:	64 Nm / 6.5 kgf-m / 47.2 lb-ft @ 8100 rpm
Transmission:	6 Speed, constant mesh
Final Drive:	Chain, DID520V0, 112 links
Frame:	Compact trellis steel frame
Clutch:	Wet, multi-plate
Front Suspension:	Telescopic, coil spring, oil damped
Front Wheel Travel:	125 mm / 4.9 in
Rear Suspension:	Link type, coil spring, oil damped, spring preload 7-step adjustable
Rear Wheel Travel:	130 mm / 5.1 in
Front Brakes:	2 x 290 mm Discs, 4 piston calipers, / ABS
Rear Brakes:	Single 240 mm disc, 1 piston caliper, / ABS
Front Wheel:	3.50 x 17, Aluminium alloy, 5-spoke
Rear Wheel:	5.00 x 17, Aluminium alloy, 5-spoke
Front Tyre:	120/70ZR17M/C (58W), tubeless
Rear Tyre:	160/60 ZR17M/C 69W, tubeless
Rake:	25o
Trail:	104 mm / 4.1 in
Dimensions:	Length 2140 mm / 84.3 in Width 730 mm / 28.7 in Height 1090 mm / 42.9 in
Wheelbase:	1445 mm / 56.9 in
Seat Height:	790 mm / 31.1 in
Ground clearance:	135mm / 5.3 in
Wet Weight:	196 kg / 432.0 lbs
Fuel Capacity:	14.5 Litres / 3.8 US gal / 3.2 Imp gal
