Suzuki GSX-R 1000 Phantom (2006) technical specifications

Suzuki GSX-R 1000 Phantom technical specifications

Suzuki GSX-R 1000 Phantom is produced in 2006. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC, displacement 998.6 cc / 60.9 cub. in , produces power 131 kW / 178 hp @ 11000rpm and 118 Nm / 12 kgf-m / 87 ft -lb @ 8500rpm. Suzuki GSX-R 1000 Phantom top speed is 292.9 km/h / 181.9 mph. Suzuki GSX-R 1000 Phantom weighs 166 kg / 366 lbs. Suzuki GSX-R 1000 Phantom has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: GSX-R 1000 Phantom
Years: 2006
Production: 200 Units
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Capacity: 998.6 cc / 60.9 cub. in
Bore x Stroke: 74.3 x 59 mm
Compression Ratio: 12.5:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Engine Oil: Synthetic, 10W/40
Exhaust: 4 into 1 into 2, Stainless steel
Induction: Electronic Fuel Injection with four 44mm throttle bodies
Ignition: Electronic ignition, Transistorized
Starting: Electric
Spark Plug: NGK, CR9EIA-9
Clutch: Cable-operated multiplate wet clutch with back torque limiter
Max Power: 131 kW / 178 hp @ 11000rpm
Max Torque: 118 Nm / 12 kgf-m / 87 ft -lb @ 8500rpm
Transmission: 6 Speed, constant mesh
Final Drive: #530 chain
Gear Ratio: 1st 2.562 / 2nd 2.052 / 3rd 1.714 / 4th 1.500 / 5th 1.360 / 6th 1.269:1
Frame: Aluminium, twin spar
Rake: 23.75°
Trail: 96 mm / 3.8 in.
Front Suspension: 43mm Kayaba inverted cartridge forks with diamond-like coating adjustable for preload, compression and rebound damping
Front Wheel Travel: 125mm / 4.9 in.
Rear Suspension: Kayaba monoshock adjustable for ride height, preload, compression and rebound damping
Rear Wheel Travel: 130 mm / 5.1 in.
Front Brakes: 2 x 310 mm discs, 4 piston caliper
Rear Brakes: Single 220 mm disc, 2 caliper
Wheels: Cast aluminium, 3 spoke
Front Tyre: 120/70 ZR17
Rear Tyre: 190/50 ZR17
Wheelbase: 1405 mm / 55.3 in.
Dimensions: Length 2030 mm / 79.9 in Width 710 mm / 28 in Height 1130 mm / 44.5 in
Seat Height: 810 mm / 31.9 in.
Ground clearance: 125 mm / 4.9 in.
Dry Weight: 166 kg / 366 lbs
Fuel Capacity: 18 Litres / 4.8 US gal / 4.0 Imp gal
Average Fuel Consumption: 6.9 l/100 km / 14.5 km/l / 34 US mpg / 41 Impmpg
Average Tank Range: 195 km / 121 miles
Standing 0 - 160 km/h / 100 mph: 5.2 sec.
Standing 0 - 100 km/h / 62 mph: 2.8 sec.
Standing 1/4 mile: 10.1 sec / 232.2 km/h / 144.3 mph
Top Speed: 292.9 km/h / 181.9 mph
