Suzuki GSX 1300R Hayabusa Limited Edition (2013) technical specifications

Suzuki GSX 1300R Hayabusa Limited Edition technical specifications

Suzuki GSX 1300R Hayabusa Limited Edition is produced in 2013. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 1340 cc / 81.8 cu-in , produces power 146 kW / 195.7 hp @ 9800 rpm and 154 Nm / 15.81 kg-m / 113.6 lb-ft @ 7200 rpm. Suzuki GSX 1300R Hayabusa Limited Edition top speed is 296.9 km/h / 184.49 mph. Suzuki GSX 1300R Hayabusa Limited Edition weighs 220 kg / 485 lbs. Suzuki GSX 1300R Hayabusa Limited Edition has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: GSX 1300R Hayabusa Limited Edition
Years: 2013
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Capacity: 1340 cc / 81.8 cu-in
Bore x Stroke: 81 x 65 mm
Compression Ratio: 12.5:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Induction: Suzuki Fuel Injection fuel injection
Ignition: Electronic
Starting: Electric
Max Power: 146 kW / 195.7 hp @ 9800 rpm
Max Torque: 154 Nm / 15.81 kg-m / 113.6 lb-ft @ 7200 rpm
Clutch: Clutch Type: Wet multi-plate, manual Clutch Actuation System: Hydraulic Clutch Spring Type: Coil Number of Clutch Springs: 6 Number of Clutch Plates: 10 Drive; 9 Driven
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 1.596 / 2nd 2.615 / 3rd 1.937 / 4th 1.526 / 5th 1.136 / 5th 1.136
Primary Drive Ratio: 1.596 (83/52)
Final Drive Ratio: 2.388 (43/18)
Frame: Design (Material): Twin-spar (aluminum alloy)
Front Suspension: Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.
Rear Suspension: Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.
Front Brakes: 2 x 310 mm Discs, 4 piston calipers
Rear Brakes: Single 260 mm disc, 1 piston caliper
Wheels Front: 17 M/C x MT3.50, cast aluminum alloy
Wheels Rear: 17 M/C x MT6.00, cast aluminum alloy
Front Tyre: 120/70 ZR17
Rear Tyre: 190/50 ZR17
Rake: 24.2°
Trail: 98 mm / 3.8 in
Dimensions: Length 2190 mm / 86.2 in Width 735 mm / 28.9 in Height 1165 mm / 45.9 in
Wheelbase: 1480 mm / 58.3in
Seat Height: 805 mm / 31.7 in
Ground Clearance: 120 mm / 4.7 in
Dry Weight: 220 kg / 485 lbs
Wet Weight: 266 kg / 586 lbs
Fuel Capacity: 21 Litres / 5.5 US gal / 4.6 Imp gal
Consumption Average: 6.1 L/100 km / 16.3 km/l / 38.3 US mpg / 46.0 Imp mpg
Standing 0 - 100km: 3.0 sec
Standing 0 - 140km: 4.4 sec
Standing 0 - 200km: 7.3 sec
Acceleration 60-140 km/h: 7.1 sec
Acceleration 100 - 140 km/h: 3.2 sec
Acceleration 140 - 180 km/h: 3.4 sec
Standing ¼ Mile: 10.2 sec
Top Speed: 296.9 km/h / 184.49 mph
