Suzuki GSR 400 (2006-08) technical specifications

Suzuki GSR 400 technical specifications

Suzuki GSR 400 is produced in 2006-08. Engine is Rour stoke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 399 cc / 24.3 cu in , produces power 38.2 kW / 52 hp @ 11000 rpm and 37 Nm / 3.8 kgf-m / 27.3 lb-ft @ 9000 rpm. Suzuki GSR 400 weighs 185 kg / 408 lbs. Suzuki GSR 400 has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: GSR 400
Years: 2006-08
Engine: Rour stoke, transverse four cylinder, DOHC, 4 valves per cylinder
Capacity: 399 cc / 24.3 cu in
Bore x Stroke: 54.6 x 42.5 mm
Compression Ratio: 12.2:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Induction: Fuel injection
Ignition: Electronic
Starting: Electric
Clutch: Wet, multiple plates, coil springs
Max Power: 38.2 kW / 52 hp @ 11000 rpm
Max Torque: 37 Nm / 3.8 kgf-m / 27.3 lb-ft @ 9000 rpm
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2.785 / 2nd 2.000 / 3rd 1.600 / 4th 1.363 / 5th 1.208 / 6th 1.086:1
Frame: Diamond
Rake: 25.2°
Trail: 104 mm / 4.1 in
Front Suspension: 43 mm Telescopic forks fully adjustable spring preload
Rear Suspension: Link-type, coil spring, oil-damped, spring preload 7-way adjustable, rebound damping force fully adjustable
Front Brakes: 2 x 320 mm Discs, 4 piston caliper
Rear Brakes: Single 240 mm disc, 1 piston caliper
Front Tyre: 120/70ZR-17
Rear Tyre: 180/55ZR-17
Dimensions: Length: 2090 mm / 82.3 in
Seat Height: 770 mm / 30.3 in
Dry Weight: 185 kg / 408 lbs
Fuel Capacity: 16.5 Litres / 4.4 US gal / 3.6 Imp gal
