Technical specifications
|
| Model: |
GS 125ES |
| Years: |
1991 |
|
Engine:
|
Four stroke, single cylinder, OHC
|
|
Capacity:
|
124 cc / 7.6 cu in
|
|
Bore x Stroke:
|
57 x 48.8 mm
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Carburetor
|
|
Ignition:
|
Coil pack
|
|
Starting:
|
Electric
|
|
Max Power:
|
10.2 kW / 14 hp @ @ 9500 rpm
|
|
Max Torque:
|
9.75 Nm / 0.99 kgf-m / 7.2 lb-ft
|
|
Clutch:
|
Wet, multi-plate
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Telescopic forks
|
|
Rear Suspension:
|
Dual shocks
|
|
Front Brakes:
|
Single 220mm disc
|
|
Rear Brakes:
|
130mm drum
|
|
Front Tyre:
|
2.75-18
|
|
Rear Tyre:
|
3.00-18
|
|
Dimensions:
|
Length: 1945 mm / 76.6 in Width: 710 mm / 28.0 in Height: 1110 mm / 43.7 in
|
|
Wheelbase:
|
1270 mm / 50.0 in
|
|
Seat Height:
|
745 mm / 29.3 in
|
|
Ground Clearance:
|
170 mm / 6.7 in
|
|
Wet Weight:
|
103 kg / 227 lbs
|
|
Fuel Capacity:
|
12 Litres / 3.2 US gal / 2.6 Imp gal
|
|
Consumption Average:
|
3.5 L/100 km / 28.3 km/l / 67 US mpg / 80 Imp mpg
|
|
Top Speed:
|
105 km/h / 65 mph
|
