Sunbeam Model 6 "Lion" (1921-37) technical specifications
Sunbeam Model 6 "Lion" is produced in 1921-37. Engine is Single cylinder, side valve, displacement 492 cc / 30.0 cu in Sunbeam Model 6 "Lion" weighs 136 kg / 300 lbs. Sunbeam Model 6 "Lion" has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Model 6 "Lion" |
| Years: | 1921-37 |
| Engine: | Single cylinder, side valve |
| Capacity: | 492 cc / 30.0 cu in |
| Bore x Stroke: | 77 x 105.5 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 5.0:1 |
| Exhaust: | Single |
| Starting: | Kick |
| Power: | 3.4 kW / 4.5 hp |
| Transmission: | 3-Speed wide ratio |
| Final Drive: | Chain |
| Gear Ratios: | 1st 13.7 / 2nd 8.2 / 3rd 4.9:1 (Side car model: 1st 14.6 / 2nd 8.7 / 3rd 5.25:1 or 15.5, 9.3 and 5.6) |
| Frame: | Single downtube cradle |
| Front Suspension: | Druid forks |
| Rear Suspension: | Rigid, spring loaded saddle |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Wheels: | Steel, laced wire spokes |
| Tyres, Front and Rear: | 3.25 x 26" (Optional: 3.50 x 26") |
| Dimensions: | Length: 2083 mm / 82" Width 813 mm / 32" |
| Wheelbase: | 1359 mm / 53.5" |
| Saddle Height: | 711 mm / 28" |
| Dry Weight: | 136 kg / 300 lbs |
| Fuel Capacity: | 11.4 L / 2.5 Imp gal / 3.0 US gal |
| Oil Capacity: | 2.3 L / 4.0 Imp pt / 4.8 US pt |
| Source: | Sunbeamsidevalve.com |
