Piaggio MP3 400 HPE (2020-2021) technical specifications

Piaggio MP3 400 HPE technical specifications

Piaggio MP3 400 HPE is produced in 2020-2021. Engine is Four stroke, single cylinder, SOHC, 4 valves and roller tappets, displacement 399 cc / 24.34 cu-in , produces power 26 kW / 35.3 hp @ 7000 rpm. Piaggio MP3 400 HPE weighs . Piaggio MP3 400 HPE has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: MP3 400 HPE
Years: 2020-2021
Engine: Four stroke, single cylinder, SOHC, 4 valves and roller tappets
Capacity: 399 cc / 24.34 cu-in
Bore x Stroke: 84 x 72 mm
Cooling System: Liquid cooled
Induction: Electronic fuel injection
Emmission: Euro 5
Lubrication: Dry sump
Ignition: Electronic with inductive exhaust and variable advance integrated in the injection CPU. Closed loop system with Lambda probe for the exhaust. Electronic immobilizer, block of injection pump when the vehicle is tilted. Traction control (ASR)
Starting: Electric with oil-bath free wheel
Max Power: 26 kW / 35.3 hp @ 7000 rpm
Max Toque: 37.7 Nm / 27.8 lb-ft @ 5500 rpm
Clutch: Centrifugal multi plate wet clutch
Transmission: CVT with torque server
Final Drive: Belt
Frame: Double cradle in high strength tubular steel
Front Suspension: Articulated quadrilateral, Electro-hydraulic suspension blocking system
Front Wheel Travel: 85 mm / 3.3 in
Rear Suspension: Dual hydraulic shock absorber with pre-adjusted spring in one of 4 positions
Rear Wheel Travel: 102 mm / 4.0 in
Front Brakes: 2x 258mm discs, one disc brake per wheel, 2 piston caliper
Rear Brakes: Single 240mm disc
ABS: ABS with braking integrated with the pedal
Wheels: Aluminium alloy
Front Rim: 13 x 3.00
Rear Rim: 14 x 4.00
Front Tyre: 2 x 110/70-13 Tubeless
Rear Tyre: 140/70-14 Tubeless
Dimensions: Length 2200 mm / 86.6 in Width 800 mm / 31.5 in
Wheelbase: 1560 mm / 61.4 in
Seat Height: 790 mm / 31.0 in
Dry Weight:
Fuel Capacity: 13.2 Litres / 3.48 US gal
