Piaggio MP3 250 (2010-11) technical specifications

Piaggio MP3 250 technical specifications

Piaggio MP3 250 is produced in 2010-11. Engine is Four stroke, single cylinder, SOHC, 4 valve, displacement 244 cc / 14.9 cub in. , produces power 16.5 kW / 22.5 hp @ 8250 rpm. Piaggio MP3 250 weighs 204 kg / 450 lbs. Piaggio MP3 250 has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: MP3 250
Years: 2010-11
Engine: Four stroke, single cylinder, SOHC, 4 valve
Capacity: 244 cc / 14.9 cub in.
Bore x Stroke: 72 x 60 mm
Cooling System: Liquid cooled
Fuel System: EFI
Ignition: Port Injected Alfa/n type with closed loop system, Lambda sensor in exhaust pipe and three-way double catalytic converter
Starting: Electric
Max Power: 16.5 kW / 22.5 hp @ 8250 rpm
Max Toque: 21 Nm / 2.14 kgf-m / 15.5 lb-ft. @ 6750 rpm
Transmission / Drive: CVT, Twist and go
Frame: Twin cradle, tubes in high tensile steel
Dimensions: Length: 2160 mm / 84 in. Width: 60 mm / 29.3 in. Height: 1350 mm / 53.2 in.
Wheelbase: 1488 mm / 58.6 in.
Seat Height: 780 mm / 30.7 in
Front Suspension: Parallelogram composed of four aluminium arms supporting two steering tubes cantilevers.
Front Wheel Travel: 85mm / 3.3 in.
Rear Suspension: 110mm / 4.3 in.
Front Brakes: 2 x 240mm discs, 2 piston caliper
Rear Brakes: Single 240mm disc
Front Tyre: 2 x 120/70 -12
Rear Tyre: 130/70 -12
Dry Weight: 204 kg / 450 lbs
Fuel Capacity: 12 Litres / 3.2 US gal
Colours: Graphite black, Cortina gray
