Piaggio Liberty 125 3V (2014) technical specifications

Piaggio Liberty 125 3V technical specifications

Piaggio Liberty 125 3V is produced in 2014. Engine is Four stroke, single cylinder, SOHC, 3 valve, displacement 124 cc / 7.6 cub in. , produces power 7.6 kW / 10.3 hp @ 7500 rpm and 10.4 Nm / 1.06 kgf-m / 7.67 lb-ft @ 6000 rpm. Piaggio Liberty 125 3V top speed is 95 km/h / 59 mph. Piaggio Liberty 125 3V has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Liberty 125 3V
Years: 2014
Engine: Four stroke, single cylinder, SOHC, 3 valve
Capacity: 124 cc / 7.6 cub in.
Bore x Stroke: 52 x 58.6 mm
Cooling System: Forced air
Lubrication: Wet sump
Fuel System: Injection
Starting: Electric, with flywheel
Max Power: 7.6 kW / 10.3 hp @ 7500 rpm
Max Torque: 10.4 Nm / 1.06 kgf-m / 7.67 lb-ft @ 6000 rpm
Clutch: Automatic centrifugal dry clutch
Transmission: CVT with torque server
Final Drive: Belt
Frame: High strength tubular steel single cradle frame
Front Suspension: Hydraulic telescopic fork
Rear Suspension: Hydraulic shock absorber with adjustable preload
Front Brakes: 240 mm Disc with hydraulic controls
Rear Brakes: 140 mm Drum
Front Tyre: 80/90 - 15
Rear Tyre: 100/80 - 14
Dimensions: Length: 1920 mm / 75.5 in. Width: 700 mm / 27.6 in.
Wheelbase: 1345 mm / 53.0 in.
Seat Height: 790 mm / 31.1 in.
Fuel Capacity: 6.5 L / 1.7 US gal
Consumption average: 3.3 L/100 km / 30.3 km/L / 71 mpg
Top Speed: 95 km/h / 59 mph
Colours: Bianco Perla, Blu Midnight, Nero Grafite, Marrone Onix
