NSU Pony (1937-53) technical specifications

NSU Pony is produced in 1937-53. Engine is Single cylinder, 2 stroke, displacement 97 cc / 5.9 cub in , produces power 2.2 kW / 3 hp @ 4700 rpm. NSU Pony top speed is 55 km/h / 34 mph (from 1937: 60 km/h / 37.3 mph). NSU Pony wet weight is 63 kg / 139 lbs. NSU Pony has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Pony
Years:	1937-53
Production:	250 000 units
Engine:	Single cylinder, 2 stroke
Capacity:	97 cc / 5.9 cub in
Bore x Stroke:	49 x 52 mm
Cooling:	Air/Oil cooled
Lubrication:	Dry sump
Oil Fuel Mixture:	1:25
Clutch:	Multi-plate friction clutch
Starting:	Kick start
Ignition:	Pradnico -magneto flywheel 6V, 15W Bosch or Noris
Carburetor:	Amal 68/412 N and after teh war BING AJ 1/14/17
Exhaust System:	Single, steel and chrome exhaust
Max Power:	2.2 kW / 3 hp @ 4700 rpm
Compression Ratio:	1:6
Transmission:	2-speed, gearshift on tank
Gear Ratios:	1st 2.91, 2nd 1.76:1
Final Drive:	Chain
Frame:	Round steel pipe
Dimensions:	Length 1970 mm / 77.6 in. Width 720 mm / 28.3 in. Height 1100 mm / 43.3 in.
Wheelbase:	1225 mm / 48.2 in.
Wheels:	26 x 2,25 in (from 1952: 26 x 2.50 in)
Brakes:	Rear. Initially reversing the pedals to engage the rear hub. Replaced in 1938 by internal brake jaw
Wet Weight:	63 kg / 139 lbs
Tank Capacity:	7.5 l / 2 US gal (from 1952: 9.5 l / 2.5 US gal)
Average Consumption:	2.2 l/100km / 45.5 km/l / 106.9 US mpg
Top Speed:	55 km/h / 34 mph (from 1937: 60 km/h / 37.3 mph)
