Norton P11 / P11A / Ranger (1969-) technical specifications
Norton P11 / P11A / Ranger is produced in 1969-. Engine is Four stroke, parallel twin cylinder, push rod, 2 valves per cylinder., displacement 745 cc / 45.5 cu in , produces power NA. Norton P11 / P11A / Ranger weighs 156.5 kg / 345 lbs. Norton P11 / P11A / Ranger has 6 photos.
Technical specifications
+ Add to 'Compare list'| Model: | P11 / P11A / Ranger |
| Years: | 1969- |
| Engine: | Four stroke, parallel twin cylinder, push rod, 2 valves per cylinder. |
| Capacity: | 745 cc / 45.5 cu in |
| Bore x Stroke: | 73 x 89 mm |
| Compression Ratio: | 7.5:1 |
| Cooling System: | Air cooled |
| Induction: | Twin 1⅛” Amal Monoblocl concentric carburetors |
| Ignition: | Lucas K2F magneto |
| Starting: | Kick |
| Max Power: | NA |
| Transmission: | 4 Speed |
| Final Drive: | Chain |
| Frame: | Modified Matchless G85 CS dual down-tube Reynolds 531 alloy steel tubing cradle frame. |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Dual Girling shocks with adjustable pre-load. |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Front Wheel: | Akront WM2-19″ |
| Rear Wheel: | WM3-18″ steel rim |
| Front Tyre: | 3.5×19 |
| Rear Tyre: | 4.00-18 |
| Seat Height: | 830 mm / 32.7 in |
| Dry Weight: | 156.5 kg / 345 lbs |
| Fuel Capacity: | 10 Litres / 2.7 US gal |
